Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 15, 2019, 04:48 PM

  • MH STACK_B 0760_5152019_101019.mp4

  • B 0760_MH STACK_5152019_095209.mp4

  • MH STACK_B 0760_5152019_112319.mp4

Date
05/15/2019
W/O
0769790
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00112
PipeID
P09227
Time
9:48 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7980
Sewer Name
B JOINT OUTFALL B - UNIT 8J
City
EL MONTE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
16
Purpose
Routine Assessment
Project
20190515DF_JOINT_OUTFALL_B_UNIT_8J
Material
Reinforced Concrete Pipe
Shape
Circular
Height
36 in.
Upstream MH
B 0760
Downstream MH
MH STACK
Dir. of Survey
Upstream
Length Surveyed
2.1 ft.
Total Length
2.1 ft.
Structural Index
3
Structural Quick
5131
Structural Rating
10
O&M Index
5
O&M Quick
5141
O&M Rating
9
Overall Index
4
Overall Quick
—
Overall Rating
19
Pipe schematic from manhole B 0760 to MH STACK
MH: B 0760MH: MH STACKupstream0 ft. MSA - Survey Abandoned - HIGH WATER0 ft. LU - Alignment Up, 45 %0.1 ft. MGP - General Photograph - STEP0.1 ft. MGO - General Observation - STACK0.1 ft. MGO - General Observation - SHELF0.1 ft. MGO - General Observation - RIM0.1 ft. SRV - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES0.6 ft. MGO - General Observation - AIRLINE2.1 ft. AMH - Downstream Manhole, Survey Begins - 9:49 AM2.1 ft. MWM - Water Mark, 100 %of cross sectional area2.1 ft. MWL - Water Level, 100 %of cross sectional area

Observation photos (10)

  • Downstream Manhole, Survey Begins - 9:49 AM

    0 ft. - Downstream Manhole, Survey Begins - 9:49 AM

  • Water Mark, 100 %of cross sectional area

    0 ft. - Water Mark, 100 %of cross sectional area

  • Water Level, 100 %of cross sectional area

    0 ft. - Water Level, 100 %of cross sectional area

  • General Observation - AIRLINE

    1.5 ft. - General Observation - AIRLINE

  • General Photograph - STEP

    2 ft. - General Photograph - STEP

  • General Observation - STACK

    2 ft. - General Observation - STACK

  • General Observation - SHELF

    2 ft. - General Observation - SHELF

  • General Observation - RIM

    2 ft. - General Observation - RIM

  • Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES

    2 ft. - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Survey Abandoned - HIGH WATER

    2.1 ft. - Survey Abandoned - HIGH WATER

All inspections of P09227Work order 0769790

Observations (11)

DistanceCodeObservation
2MGPSTEP
2.1MSAHIGH WATER
2.1LU—
0AMH9:49 AM
1.5MGOAIRLINE
2MGOSTACK
2MGOSHELF
2MGORIM
2SRV—
0MWM—
0MWL—

Properties (7)

additional_info
VIEW OF THE UPLEG FROM THE D/S SIPHON
custom_field_three
REINFORCEMENT VISIBLE
custom_field_two
5
customer
LACSD
datetime
2019-05-15T09:48:12-07:00
documentation
FRANKLIN, CASTILLO, BRAR
is_lateral_inspection
false
