Wastewater/Activity/PacpInspection/1.0May 3, 2019, 08:39 AM
H 0611_H JOINT_532019_024512.mp4
- Date
- 05/03/2019
- W/O
- 0769645
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00190
- PipeID
- P21859
- Time
- 1:39 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1195
- Sewer Name
- H JOINT OUTFALL H - UNIT 8G
- City
- WEST COVINA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 24
- Purpose
- Routine Assessment
- Project
- 20190503MDM_JOINT_OUTFALL_H_UNIT_8G
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 48 in.
- Upstream MH
- H 0611
- Downstream MH
- H JOINT
- Dir. of Survey
- Downstream
- Length Surveyed
- 4.8 ft.
- Total Length
- 4.8 ft.
- Structural Index
- 3
- Structural Quick
- 3121
- Structural Rating
- 5
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 5
Observation photos (5)
1 ft. - General Observation - V NOTCH IN MH
2 ft. - General Observation - 95% MAG COAT START
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, - BLISTERING PEELING CONCRETE
2 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, - SEVERE AGG SPORATIC
4.6 ft. - General Observation - H JOINT
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 4.6 | MGO | H JOINT |
| 1 | MGO | V NOTCH IN MH |
| 4.8 | AMH | 2:55AM |
| 2 | MGO | 95% MAG COAT START |
| 2 | SSS | BLISTERING PEELING CONCRETE |
| 0 | AMH | 2:45AM |
| 0 | MWM | — |
| 0 | MWL | — |
| 2 | SAV | SEVERE AGG SPORATIC |
Properties (6)
- custom_field_three
- SEVERE AGG SPORATIC- M90% MAG COAT
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-05-03T01:39:16-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,RUVALCABA
- is_lateral_inspection
- false
