Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 1, 2019, 09:24 AM

  • B 0412_B 0411_312019_012926.mp4

Date
03/01/2019
W/O
0750457
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00092
PipeID
P08924
Time
1:24 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1134R
Sewer Name
B JOINT OUTFALL B - UNIT 5B
City
ARACADIA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
03
Purpose
Maintenance Related
Project
20190301MDM_JOINT_OUTFALL_B_UNIT_5B
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
B 0412
Downstream MH
B 0411
Dir. of Survey
Downstream
Length Surveyed
367.7 ft.
Total Length
367.7 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
3A21
O&M Rating
40
Overall Index
2
Overall Quick
—
Overall Rating
40
Pipe schematic from manhole B 0412 to B 0411
MH: B 0412MH: B 0411downstream0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:25AM60.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open130.9 ft. RFJ - Roots Fine Joint, from 09 to 03 o'clock, within 8 inches of joint: YESR - 3%140 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Capped153 ft. RFJ - Roots Fine Joint, from 12 to 05 o'clock, within 8 inches of joint: YESR - 3%159.7 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 5 %, within 8 inches of joint: YESR189.3 ft. RFJ - Roots Fine Joint, from 09 to 03 o'clock, within 8 inches of joint: YESR - 4%191 ft. RMJ - Roots Medium Joint, from 09 to 03 o'clock, 10 %, within 8 inches of joint: YESR199.5 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 5 %, within 8 inches of joint: YESR212.9 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 5 %, within 8 inches of joint: YESR223.5 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 25 %, within 8 inches of joint: YESR240.9 ft. RFJ - Roots Fine Joint, from 08 to 04 o'clock, within 8 inches of joint: YESR - 3%248.9 ft. RFJ - Roots Fine Joint, from 08 to 04 o'clock, within 8 inches of joint: YESR - 4%256.8 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 10 %, within 8 inches of joint: YESR275.4 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 20 %, within 8 inches of joint: YESR280.4 ft. RMJ - Roots Medium Joint, from 11 to 03 o'clock, 10 %, within 8 inches of joint: YESR291.1 ft. TFD - Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open-99% ROOTS291.1 ft. RML - Roots Medium Lateral, from 01 to 05 o'clock, 5 %, within 8 inches of joint: YES291.5 ft. RMJ - Roots Medium Joint, from 08 to 04 o'clock, 5 %, within 8 inches of joint: YESR298.7 ft. RFJ - Roots Fine Joint, from 11 to 04 o'clock, within 8 inches of joint: YESR - 3%313.7 ft. RFJ - Roots Fine Joint, from 09 to 03 o'clock, within 8 inches of joint: YESR - 2%335.6 ft. RFJ - Roots Fine Joint, from 09 to 03 o'clock, within 8 inches of joint: YESR - 2%367.2 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active367.7 ft. AMH - Downstream Manhole, Survey Ends - 1:50AM

Observation photos (5)

  • Roots Medium Joint, from 09 to 03 o'clock, 10 %, within 8 inches of joint: YESR

    191 ft. - Roots Medium Joint, from 09 to 03 o'clock, 10 %, within 8 inches of joint: YESR

  • Roots Medium Joint, from 08 to 04 o'clock, 25 %, within 8 inches of joint: YESR

    223.5 ft. - Roots Medium Joint, from 08 to 04 o'clock, 25 %, within 8 inches of joint: YESR

  • Roots Medium Joint, from 08 to 04 o'clock, 10 %, within 8 inches of joint: YESR

    256.8 ft. - Roots Medium Joint, from 08 to 04 o'clock, 10 %, within 8 inches of joint: YESR

  • Roots Medium Joint, from 08 to 04 o'clock, 20 %, within 8 inches of joint: YESR

    275.4 ft. - Roots Medium Joint, from 08 to 04 o'clock, 20 %, within 8 inches of joint: YESR

  • Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open-99% ROOTS

    291.1 ft. - Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open-99% ROOTS

All inspections of P08924Work order 0750457

Observations (26)

DistanceCodeObservation
60.2TFOpen
313.7RFJ2%
212.9RMJ—
130.9RFJ3%
189.3RFJ4%
191RMJ—
335.6RFJ2%
0MWL—
159.7RMJ—
367.2MGOConn. @ Mh, 3 O' Clock. Active
240.9RFJ3%
199.5RMJ—
291.1TFDOpen-99% ROOTS
140TFCCapped
291.5RMJ—
275.4RMJ—
280.4RMJ—
256.8RMJ—
153RFJ3%
223.5RMJ—
367.7AMH1:50AM
248.9RFJ4%
0MWM—
298.7RFJ3%
0AMH1:25AM
291.1RML—

Properties (5)

additional_info
POST ROOT EVALUATION ONLY
customer
LACSD
datetime
2019-03-01T01:24:46-08:00
documentation
MARTIN,REVELES,OLIVER 111,CASTILLO
is_lateral_inspection
false
