Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Apr 19, 2019, 07:32 AM

  • 05 1421_05 1431_4192019_025138.mp4

Date
04/19/2019
W/O
0766293
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00513
PipeID
P06652
Time
12:32 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1182
Sewer Name
05 REDONDO BEACH BOULEVARD EXTENSION TRUNK
City
GARDENA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
18
Purpose
Capital Improvement Program Assesment
Project
20190419MDM_REDONDO_BEACH_BOULEVARD_EXTENSION_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
05 1431
Downstream MH
05 1421
Dir. of Survey
Upstream
Length Surveyed
35.8 ft.
Total Length
35.8 ft.
Structural Index
3
Structural Quick
3222
Structural Rating
10
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
10
Pipe schematic from manhole 05 1431 to 05 1421
MH: 05 1431MH: 05 1421upstream0 ft. AMH - Downstream Manhole, Survey Ends - 3:05AM0.5 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active0.5 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active16.2 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H17.7 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H31.2 ft. FC - Fracture Circumferential, from 08 to 11 o'clock, within 8 inches of joint: YES - HAIRLINE31.2 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H35.8 ft. AMH - Downstream Manhole, Survey Begins - 2:55AM35.8 ft. MWL - Water Level, 0 %of cross sectional area - NO FLOW35.8 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active35.8 ft. MWM - Water Mark, 10 %of cross sectional area

Observation photos (2)

  • Water Level, 0 %of cross sectional area - NO FLOW

    0 ft. - Water Level, 0 %of cross sectional area - NO FLOW

  • Downstream Manhole, Survey Ends - 3:05AM

    35.8 ft. - Downstream Manhole, Survey Ends - 3:05AM

All inspections of P06652Work order 0766293

Observations (11)

DistanceCodeObservation
35.8AMH3:05AM
0AMH2:55AM
35.3MGOConn. @ Mh, 9 O' Clock. Active
18.1FLH
19.6FCH
0MWLNO FLOW
0MGOConn. @ Mh, 9 O' Clock. Active
0MWM—
35.3MGOConn. @ Mh, 3 O' Clock. Active
4.6FCHAIRLINE
4.6FLH

Properties (6)

custom_field_three
HAIRLINE FRACTURES
custom_field_two
3
customer
LACSD
datetime
2019-04-19T00:32:48-07:00
documentation
MARTIN,REVELES,OLIVER 111,RUVALCABA
is_lateral_inspection
false
