Wastewater/Activity/PacpInspection/1.0Apr 19, 2019, 07:28 AM
05 2409_05 1422_4192019_013603.mp4
- Date
- 04/19/2019
- W/O
- 0766293
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00513
- PipeID
- P06642
- Time
- 12:28 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1182
- Sewer Name
- 05 REDONDO BEACH BOULEVARD EXTENSION TRUNK
- City
- GARDENA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 18
- Purpose
- Capital Improvement Program Assesment
- Project
- 20190419MDM_REDONDO_BEACH_BOULEVARD_EXTENSION_TRUNK
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Upstream MH
- 05 2409
- Downstream MH
- 05 1422
- Dir. of Survey
- Downstream
- Length Surveyed
- 10.1 ft.
- Total Length
- 10.1 ft.
- Structural Index
- 3
- Structural Quick
- 3221
- Structural Rating
- 8
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (2)
3.2 ft. - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES, Start - HAIRLINE
3.2 ft. - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES, Start - HAIRLINE
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 0 | AMH | 1:35AM |
| 0 | MGO | Conn. @ Mh, 9 O' Clock. Active |
| 3.2 | FL | HAIRLINE |
| 10.1 | FL | H |
| 10.1 | MGO | Conn. @ Mh, 3 O' Clock. Active |
| 10.1 | FL | H |
| 10.1 | MGO | Conn. @ Mh, 12 O' Clock. OPEN |
| 3.2 | FC | H |
| 0 | MWM | — |
| 3.2 | FL | HAIRLINE |
| 0 | MWL | — |
| 0 | MGO | Conn. @ Mh, 3 O' Clock. Active |
Properties (6)
- custom_field_three
- HAIRLINE FRACTURE JOINT TO JOINT LONGER
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2019-04-19T00:28:28-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,RUVALCABA
- is_lateral_inspection
- false
