Wastewater/Activity/PacpInspection/1.0Apr 9, 2019, 10:20 AM
B 0346_B 0331_04092019_032452.mp4
- Date
- 04/09/2019
- W/O
- 756066
- Weather
- Dry
- Operator/Surveyor
- J. BUENROSTRO
- Sewer ID
- Z00090
- PipeID
- P08858
- Time
- 3:20 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K5850
- Sewer Name
- B JOINT OUTFALL B - UNIT 4B
- City
- TEMPLE CITY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 15
- Purpose
- Routine Assessment
- Project
- WO_756066_TV15045_MAR2019
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 21 in.
- Width
- 21 in.
- Upstream MH
- B 0346
- Downstream MH
- B 0331
- Dir. of Survey
- Downstream
- Length Surveyed
- 32.5 ft.
- Total Length
- 32.7 ft.
- Structural Index
- 2
- Structural Quick
- 3111
- Structural Rating
- 4
- O&M Index
- 3
- O&M Quick
- 4122
- O&M Rating
- 8
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 12
Observation photos (3)
2.2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
2.4 ft. - Surface Roughness Increased, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
10.1 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (15)
| Distance | Code | Observation |
|---|---|---|
| 29.7 | DAGS | — |
| 0 | MGO | SERVICE CONNECTION AT 3 O' CLOCK AT MH |
| 0 | AMH | B 0346 |
| 0 | MWL | — |
| 0 | MGO | SPLASHING DUE TO HEAVY FLOW |
| 2.2 | DAGS | — |
| 10.1 | SRI | — |
| 29.7 | SAP | — |
| 2.4 | DAZ | MAG COATING |
| 32.5 | AMH | B 0331 |
| 0 | MWM | — |
| 2.4 | SRI | — |
| 29.7 | DAZ | — |
| 10.1 | SAP | — |
| 32.5 | MGO | SERVICE CONNECTION AT 9 O'CLOCK AT MH |
Properties (6)
- additional_info
- SC366090
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2019-04-09T03:20:01-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
