Wastewater/Activity/PacpInspection/1.0Apr 25, 2019, 06:07 PM
A 0323_A 0322_4252019_114613.mp4
- Date
- 04/25/2019
- W/O
- 0767441
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00325
- PipeID
- P08233
- Time
- 11:07 AM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7970
- Sewer Name
- A JOA-1A SAN JOSE CREEK WRP INTERCEPTOR
- City
- EL MONTE
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 28
- Purpose
- Capital Improvement Program Assesment
- Project
- 20190425DF_JOA_1A_SAN_JOSE_CREEK_WRP_INT
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 60 in.
- Upstream MH
- A 0323
- Downstream MH
- A 0322
- Dir. of Survey
- Downstream
- Length Surveyed
- 625.4 ft.
- Total Length
- 625.4 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 3
Observation photos (9)
0.2 ft. - Water Mark, 35 %of cross sectional area
0.2 ft. - Water Level, 30 %of cross sectional area
25 ft. - Lining Change, Other (enter details in Field 39) - PLASTIC
51.6 ft. - Lining Failure Wrinkled, from 02 to 05 o'clock, within 8 inches of joint: YES, Start
151 ft. - General Photograph
262.7 ft. - General Photograph
301.2 ft. - General Photograph
450.5 ft. - General Photograph
582.8 ft. - General Photograph
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 450.5 | MGP | — |
| 625.4 | AMH | 12:06 PM |
| 620.5 | MGO | Grease Throughout The Reach (5%) |
| 262.7 | MGP | — |
| 0.2 | MWM | — |
| 582.8 | MGP | — |
| 301.2 | MGP | — |
| 25 | MLC | PLASTIC |
| 51.6 | LFW | — |
| 620.4 | LFW | — |
| 0 | AMH | 11:15 AM |
| 0.2 | MWL | — |
| 151 | MGP | — |
Properties (6)
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-04-25T11:07:20-07:00
- documentation
- FRANKLIN, CASTILLO, BRAR
- is_lateral_inspection
- false
- year_laid
- 19800403
