Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 28, 2018, 07:07 AM

  • 05 0905_05 0375 _12272018_231301.mp4

Date
12/27/2018
W/O
740636
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00547
PipeID
P06136
Time
11:07 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6306
Sewer Name
05 120TH STREET EXTENSION TRUNK
City
HAWTHRONE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
13
Purpose
Routine Assessment
Project
WO_740636_TV05004_DEC2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
05 0905
Downstream MH
05 0375
Dir. of Survey
Downstream
Length Surveyed
88.9 ft.
Total Length
88.9 ft.
Structural Index
3
Structural Quick
3B2B
Structural Rating
85
O&M Index
3
O&M Quick
3B00
O&M Rating
51
Overall Index
3
Overall Quick
—
Overall Rating
136
Pipe schematic from manhole 05 0905 to 05 0375
MH: 05 0905MH: 05 0375downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 05 09053.3 ft. DSZ - Deposits Settled Other, 15 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start3.3 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start3.3 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start88.9 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish88.9 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK88.9 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish88.9 ft. DSZ - Deposits Settled Other, 15 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish88.9 ft. AMH - Downstream Manhole, Survey Ends - 05 0375

Observation photos (2)

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    3.3 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    3.3 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P06136Work order 740636

Observations (11)

DistanceCodeObservation
88.9SSS—
88.9MGOCONNECTION AT MH 9 O'CLOCK
0MWL—
88.9SAV—
0MWM—
3.3DSZ—
3.3SSS—
0AMH05 0905
88.9DSZ—
3.3SAV—
88.9AMH05 0375

Properties (6)

additional_info
SC365490
custom_field_two
2
customer
LACSD
datetime
2018-12-27T23:07:35-08:00
documentation
PROPIPE
is_lateral_inspection
false
