Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 1, 2018, 07:49 AM

  • 05 0185_05 0184 _11012018_000249.mp4

Date
11/01/2018
W/O
735493
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00431
PipeID
P05477
Time
12:49 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6207
Sewer Name
05 DISTRICT #5 MAIN TRUNK
City
INGLEWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
06
Purpose
Routine Assessment
Project
WO_735493_TV05228_NOV2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
05 0185
Downstream MH
05 0184
Dir. of Survey
Downstream
Length Surveyed
331.2 ft.
Total Length
331.2 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
3123
O&M Rating
13
Overall Index
2
Overall Quick
—
Overall Rating
13
Pipe schematic from manhole 05 0185 to 05 0184
MH: 05 0185MH: 05 0184downstream0 ft. AMH - Upstream Manhole, Survey Begins - 05 01850 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 20 %of cross sectional area6.1 ft. RFL - Roots Fine Lateral, at 10 o'clock6.1 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"28.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"64.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"64.3 ft. RFL - Roots Fine Lateral, at 10 o'clock66.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"66.9 ft. RFL - Roots Fine Lateral, at 02 o'clock112.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"115.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"122.5 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"125 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"165.9 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"201.1 ft. TF - Tap Factory Made, at 03 o'clock, -, within 8 inches of joint: NO, 6"244.2 ft. RML - Roots Medium Lateral, at 10 o'clock, 25 %, within 8 inches of joint: NO244.2 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"244.2 ft. RFC - Roots Fine Connection, at 10 o'clock246.7 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"317.8 ft. DSZ - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Start331.2 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK331.2 ft. AMH - Downstream Manhole, Survey Ends - 05 0184331.2 ft. DSZ - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Finish

Observation photos (1)

  • Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Start

    317.8 ft. - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Start

All inspections of P05477Work order 735493

Observations (24)

DistanceCodeObservation
331.2MGOCONNECTION AT MH 3 O'CLOCK
28.8TF—
64.3TF—
112.3TF—
0AMH05 0185
64.3RFL—
165.9TF—
246.7TF—
244.2RML—
317.8DSZ—
115.3TF—
66.9TF—
331.2AMH05 0184
331.2DSZ—
6.1RFL—
201.1TF—
66.9RFL—
0MWL—
0MWM—
122.5TF—
244.2TF—
125TF—
244.2RFC—
6.1TF—

Properties (7)

additional_info
SC365235
custom_field_two
4
customer
LACSD
datetime
2018-11-01T00:49:27-07:00
documentation
PROPIPE
is_lateral_inspection
false
lining
CIPP
