Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 21, 2019, 10:00 AM

  • 22 0236_22 0235 _01212019_022042.mp4

Date
01/21/2019
W/O
745548
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00793
PipeID
P16518
Time
2:00 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6361
Sewer Name
22 CAMERON TRUNK, SECTS 1,2,&3
City
WEST COVINA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
35
Purpose
Routine Assessment
Project
RFIR_WO_745548_TV22160_JAN2019
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
22 0235
Downstream MH
22 0236
Dir. of Survey
Upstream
Length Surveyed
419.9 ft.
Total Length
419.9 ft.
Structural Index
3
Structural Quick
3P2O
Structural Rating
413
O&M Index
2
O&M Quick
2P00
O&M Rating
166
Overall Index
2
Overall Quick
—
Overall Rating
579
Pipe schematic from manhole 22 0235 to 22 0236
MH: 22 0235MH: 22 0236upstream0 ft. MGO - General Observation - ACTIVE CONNECTION AT 3 AND 9 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Ends - 22 02360 ft. MGO - General Observation - COCKROACHES IN MANHOLE1.8 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish1.8 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish1.8 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish81.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"84.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"136.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"139.4 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"142.9 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"181.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"184.7 ft. TFC - Tap Factory Made Capped, at 11 o'clock, -, within 8 inches of joint: NO, 6"228.9 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"232.5 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"273.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"277.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"322.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"325.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"377.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"379.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"413 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start417.9 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start417.9 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start419.9 ft. AMH - Downstream Manhole, Survey Begins - 22 0235419.9 ft. MWM - Water Mark, 25 %of cross sectional area419.9 ft. MWL - Water Level, 20 %of cross sectional area

Observation photos (4)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    6.9 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    419.9 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P16518Work order 745548

Observations (27)

DistanceCodeObservation
142.6TFC—
338.1TFC—
191TFA—
97TF—
2DAGS—
280.5TFA—
418.1SAP—
146TFC—
42.4TFC—
418.1DAGS—
0AMH22 0235
40TFC—
283.7TFC—
187.4TFC—
0MWM—
0MWL—
2SAP—
335.2TFC—
94TFC—
277TBA—
419.9MGOACTIVE CONNECTION AT 3 AND 9 O'CLOCK
419.9AMH22 0236
418.1SSS—
238.4TFC—
6.9SSS—
235.2TFC—
419.9MGOCOCKROACHES IN MANHOLE

Properties (6)

additional_info
SC365678
custom_field_two
2
customer
LACSD
datetime
2019-01-21T02:00:15-08:00
documentation
PRO PIPE
is_lateral_inspection
false
