Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 18, 2018, 08:24 AM

  • B 0689_B 0688 _18092018_012446.mp4

Date
09/18/2018
W/O
724243
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00110
PipeID
P09359
Time
1:24 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6107
Sewer Name
B JOINT OUTFALL B - UNIT 8G
City
DUARTE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
09
Purpose
Routine Assessment
Project
WO_724243_TV15057_SEP2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
B 0689
Downstream MH
B 0688
Dir. of Survey
Downstream
Length Surveyed
205.1 ft.
Total Length
205.1 ft.
Structural Index
3
Structural Quick
3G00
Structural Rating
126
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
126
Pipe schematic from manhole B 0689 to B 0688
MH: B 0689MH: B 0688downstream0 ft. AMH - Upstream Manhole, Survey Begins - B 06890 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK3.6 ft. SAV - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start21.6 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start21.6 ft. SAP - Surface Aggregate Projecting, from 11 to 01 o'clock, within 8 inches of joint: YES21.6 ft. SAV - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Finish80.8 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"205.1 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish205.1 ft. AMH - Downstream Manhole, Survey Ends - B 0688

Observation photos (3)

  • Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start

    3.6 ft. - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    21.6 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 11 to 01 o'clock, within 8 inches of joint: YES

    21.6 ft. - Surface Aggregate Projecting, from 11 to 01 o'clock, within 8 inches of joint: YES

All inspections of P09359Work order 724243

Observations (11)

DistanceCodeObservation
205.1SAP—
0AMHB 0689
21.6SAP—
21.6SAP—
21.6SAV—
0MWM—
3.6SAV—
80.8TF—
0MWL—
205.1AMHB 0688
0MGOCONNECTION AT MH 9 O'CLOCK

Properties (4)

additional_info
SC364823
custom_field_two
3
customer
LACSD
datetime
2018-09-18T01:24:15-07:00
