Wastewater/Activity/PacpInspection/1.0Oct 23, 2018, 07:48 AM
H 1058H 0951 District 21_112118101644.mpg
- Date
- 10/23/2018
- W/O
- 718172
- Weather
- Dry
- Operator/Surveyor
- B. FUGATE
- Sewer ID
- Z01005
- PipeID
- P15365
- Time
- 12:48 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K1685
- Sewer Name
- H JOINT OUTFALL H - UNIT 7C
- City
- CITY OF INDUSTRY
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 21
- Page No.
- 34
- Purpose
- Routine Assessment
- Project
- WO_718172_TV21087_AUG2018
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 36 in.
- Width
- 36 in.
- Upstream MH
- H 1058
- Downstream MH
- H 0951
- Dir. of Survey
- Downstream
- Length Surveyed
- 33 ft.
- Total Length
- 33.1 ft.
- Structural Index
- 3
- Structural Quick
- 5136
- Structural Rating
- 23
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 23
Observation photos (2)
2.1 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
21.1 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 21.1 | SAV | — |
| 0 | MWM | — |
| 33.1 | SAP | — |
| 21.1 | SAP | — |
| 2.1 | SAV | — |
| 0 | AMH | H 1058 |
| 0 | MWL | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 33.1 | AMH | H 0951 |
| 31.2 | SRV | — |
Properties (6)
- additional_info
- SC365228
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-10-23T00:48:00-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
