Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 24, 2018, 08:16 AM

  • 01 0693_01 0692_20180824_012944.mp4

Date
08/24/2018
W/O
723858
Weather
Dry
Operator/Surveyor
N.ZAHREDDINE
Sewer ID
Z00199
PipeID
P01402
Time
1:16 AM
Certificate
U-109-7948
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K6060
Sewer Name
01 CALIFORNIA AVENUE EXTENSION TRUNK
City
South Gate
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
11
Purpose
Routine Assessment
Project
WO_723858_TV01117_SEP2018
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
33 in.
Width
33 in.
Upstream MH
01 0693
Downstream MH
01 0692
Dir. of Survey
Downstream
Length Surveyed
445.5 ft.
Total Length
445.5 ft.
Structural Index
3
Structural Quick
3300
Structural Rating
9
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
3
Overall Quick
—
Overall Rating
13
Pipe schematic from manhole 01 0693 to 01 0692
MH: 01 0693MH: 01 0692downstream0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01 06930 ft. MWL - Water Level, 20 %of cross sectional area2 ft. MGO - General Observation - MAG COAT 60%35.9 ft. SAP - Surface Aggregate Projecting, from 01 to 03 o'clock, within 8 inches of joint: NO173.2 ft. SAV - Surface Aggregate Visible, from 01 to 04 o'clock, within 8 inches of joint: NO400.8 ft. SAP - Surface Aggregate Projecting, from 09 to 11 o'clock, within 8 inches of joint: NO444.9 ft. MGO - General Observation - ROACHES IN MH445.5 ft. AMH - Downstream Manhole, Survey Ends - 01 0692

Observation photos (3)

  • Surface Aggregate Projecting, from 01 to 03 o'clock, within 8 inches of joint: NO

    35.9 ft. - Surface Aggregate Projecting, from 01 to 03 o'clock, within 8 inches of joint: NO

  • Surface Aggregate Visible, from 01 to 04 o'clock, within 8 inches of joint: NO

    173.2 ft. - Surface Aggregate Visible, from 01 to 04 o'clock, within 8 inches of joint: NO

  • Surface Aggregate Projecting, from 09 to 11 o'clock, within 8 inches of joint: NO

    400.8 ft. - Surface Aggregate Projecting, from 09 to 11 o'clock, within 8 inches of joint: NO

All inspections of P01402Work order 723858

Observations (9)

DistanceCodeObservation
0MWM—
2MGOMAG COAT 60%
173.2SAV—
35.9SAP—
444.9MGOROACHES IN MH
445.5AMH01 0692
0AMH01 0693
0MWL—
400.8SAP—

Properties (5)

custom_field_two
3
customer
LACSD
datetime
2018-08-24T01:16:53-07:00
documentation
PRO PIPE
is_lateral_inspection
false
