Wastewater/Activity/PacpInspection/1.0Jun 9, 2017, 04:28 PM
19 0180A_19 0180_692017_092907.mp4
- Date
- 06/09/2017
- W/O
- 0645066
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00719
- PipeID
- P15149
- Time
- 9:28 AM
- Certificate
- 415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7431
- Sewer Name
- 19 CERRITOS TRUNK
- City
- CERRITOS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 19
- Page No.
- 05
- Purpose
- Routine Assessment
- Project
- 20170608DF_CERRITOS_TRUNK
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Upstream MH
- 19 0180A
- Downstream MH
- 19 0180
- Dir. of Survey
- Downstream
- Length Surveyed
- 220.6 ft.
- Total Length
- 220.6 ft.
- Structural Index
- 2
- Structural Quick
- 2100
- Structural Rating
- 2
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 4
Observation photos (4)
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
4 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Start
95.8 ft. - General Photograph - GASKET PEELING/HANGING 12 TO 2 O'CLOCK
151.9 ft. - General Photograph - SPALLING
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 218.6 | DAE | — |
| 4 | DAE | — |
| 0 | MGO | ROACHES @ MH |
| 0 | AMH | 9:28 AM |
| 151.9 | MGP | SPALLING |
| 218.6 | SSS | — |
| 220.6 | AMH | 9:44 AM |
| 2 | SSS | — |
| 95.8 | MGP | GASKET PEELING/HANGING 12 TO 2 O'CLOCK |
| 0 | MWM | — |
| 0 | MWL | — |
Properties (5)
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-06-09T09:28:48-07:00
- documentation
- FRANKLIN, IGNACIO
- is_lateral_inspection
- false
