Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 23, 2016, 11:36 AM

  • 22 1132_B 1012 _23062016_043713.mp4

Date
06/23/2016
W/O
563409
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00925
PipeID
P21749
Time
4:36 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3540
Sewer Name
B JOINT OUTFALL B - UNIT 8G RELIEF
City
DUARTE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
08
Purpose
Routine Assessment
Project
WO_563409_TV22070_JUNE2016
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
B 1012
Downstream MH
22 1132
Dir. of Survey
Upstream
Length Surveyed
196.3 ft.
Total Length
196.3 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
2G00
O&M Rating
78
Overall Index
2
Overall Quick
—
Overall Rating
78
Pipe schematic from manhole B 1012 to 22 1132
MH: B 1012MH: 22 1132upstream0 ft. AMH - Upstream Manhole, Survey Ends - 22 11320 ft. MGO - General Observation - COCKROACHES IN MANHOLE1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish194.3 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start196.3 ft. MWM - Water Mark, 15 %of cross sectional area196.3 ft. MGO - General Observation - COCKROACHES IN MANHOLE196.3 ft. AMH - Downstream Manhole, Survey Begins - B 1012196.3 ft. MWL - Water Level, 5 %of cross sectional area

Observation photos (3)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    196.3 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P21749Work order 563409

Observations (8)

DistanceCodeObservation
0MWM—
195.3DAGS—
0MGOCOCKROACHES IN MANHOLE
0AMHB 1012
2DAGS—
0MWL—
196.3AMH22 1132
196.3MGOCOCKROACHES IN MANHOLE

Properties (7)

additional_info
SC305774
custom_field_two
4
customer
LACSD
datetime
2016-06-23T04:36:56-07:00
documentation
PRO PIPE
is_lateral_inspection
false
year_laid
35802
