Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 29, 2018, 11:13 AM

  • 16 0307_16 0306_11292018_035115.mp4

Date
11/29/2018
W/O
0742114
Weather
Light Rain
Operator/Surveyor
MARTIN
Sewer ID
Z00665
PipeID
P13358
Time
3:13 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1065
Sewer Name
16 SAN MARINO OUTFALL TRUNK
City
ALHAMBRA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
21
Purpose
Routine Assessment
Project
20181129MDM_SAN_MARINO_OUTFALL_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
20 in.
Upstream MH
16 0307
Downstream MH
16 0306
Dir. of Survey
Downstream
Length Surveyed
319.1 ft.
Total Length
319.1 ft.
Structural Index
3
Structural Quick
4232
Structural Rating
20
O&M Index
2
O&M Quick
3122
O&M Rating
7
Overall Index
3
Overall Quick
—
Overall Rating
27
Pipe schematic from manhole 16 0307 to 16 0306
MH: 16 0307MH: 16 0306downstream0 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 3:50AM0 ft. MWM - Water Mark, 30 %of cross sectional area2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start10.4 ft. FC - Fracture Circumferential, from 01 to 02 o'clock, within 8 inches of joint: YES - HAIRLINE14.7 ft. FM - Fracture Multiple, from 08 to 12 o'clock, within 8 inches of joint: YES - HAIRLINE17.5 ft. FM - Fracture Multiple, from 08 to 11 o'clock, within 8 inches of joint: YES - H42.7 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Active54.2 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H85.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open106.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open132.1 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open150.4 ft. TFD - Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Active-50% ROOTS150.4 ft. RML - Roots Medium Lateral, from 07 to 10 o'clock, 10 %, within 8 inches of joint: NO154.4 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H181 ft. TF - Tap Factory Made, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Active188 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - H199.1 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Active235.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open283.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open287.8 ft. FC - Fracture Circumferential, from 01 to 04 o'clock, within 8 inches of joint: YES - H288.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 2" - Open319.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish319.1 ft. AMH - Downstream Manhole, Survey Ends - 4:20AM

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • Fracture Multiple, from 08 to 12 o'clock, within 8 inches of joint: YES - HAIRLINE

    14.7 ft. - Fracture Multiple, from 08 to 12 o'clock, within 8 inches of joint: YES - HAIRLINE

All inspections of P13358Work order 0742114

Observations (25)

DistanceCodeObservation
287.8FCH
235.2TFOpen
283.4TFOpen
0MGOConn. @ Mh, 3 O' Clock. Active
154.4FLH
319.1DAGS—
188FCH
42.7TFActive
17.5FMH
319.1AMH4:20AM
85.6TFOpen
181TFActive
150.4TFDActive-50% ROOTS
54.2FLH
2DAGS—
14.7FMHAIRLINE
150.4RML—
0MWL—
0AMH3:50AM
0MWM—
288.8TFOpen
106.4TFOpen
199.1TFAActive
132.1TFOpen
10.4FCHAIRLINE

Properties (6)

custom_field_three
HAIRLINES
custom_field_two
4
customer
LACSD
datetime
2018-11-29T03:13:15-08:00
documentation
MARTIN,REVELES,OLIVER 111,BRAR
is_lateral_inspection
false
