Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 14, 2016, 09:09 AM

  • 19 0141_19 0140_20160314_032622.mp4

Date
03/14/2016
W/O
557968
Weather
Dry
Operator/Surveyor
J. HARTOOG
Sewer ID
Z00722
PipeID
P15331
Time
2:09 AM
Certificate
U-507-03-3386
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K3223
Sewer Name
19 EAST ARTESIA TRUNK, SECTS 1,2,3,&5
City
CERRITOS, CA
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 19
Page No.
03
Purpose
Routine Assessment
Project
WO_557968_TV19021_2016MAR
Sewer Type
GRAVITY
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Upstream MH
19 0141
Downstream MH
19 0140
Dir. of Survey
Downstream
Length Surveyed
330.5 ft.
Total Length
330.5 ft.
Structural Index
3
Structural Quick
3411
Structural Rating
13
O&M Index
1
O&M Quick
2114
O&M Rating
6
Overall Index
2
Overall Quick
—
Overall Rating
19
Pipe schematic from manhole 19 0141 to 19 0140
MH: 19 0141MH: 19 0140downstream0 ft. MWM - Water Mark, 35 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 19 01412.3 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start13.7 ft. CM - Crack Multiple, from 12 to 02 o'clock, within 8 inches of joint: YES26.8 ft. CM - Crack Multiple, from 11 to 05 o'clock, within 8 inches of joint: YES, Start33.1 ft. CM - Crack Multiple, from 11 to 05 o'clock, within 8 inches of joint: YES, Finish37.8 ft. RFJ - Roots Fine Joint, from 09 to 11 o'clock, within 8 inches of joint: YES43.7 ft. CC - Crack Circumferential, from 07 to 05 o'clock, within 8 inches of joint: YES48.5 ft. RFJ - Roots Fine Joint, from 03 to 04 o'clock, within 8 inches of joint: YES58.8 ft. RFJ - Roots Fine Joint, from 03 to 05 o'clock, within 8 inches of joint: YES, Start72.1 ft. RFJ - Roots Fine Joint, from 03 to 05 o'clock, within 8 inches of joint: YES, Finish184.6 ft. CM - Crack Multiple, from 12 to 02 o'clock, within 8 inches of joint: YES199.5 ft. CM - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Start245.1 ft. RFJ - Roots Fine Joint, at 03 o'clock, within 8 inches of joint: NO296.9 ft. CM - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Finish327 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish330.5 ft. AMH - Downstream Manhole, Survey Ends - 19 0140330.5 ft. MGO - General Observation - LATERAL AT MH 9 OCLOCK CAPPED

Observation photos (9)

  • Water Mark, 35 %of cross sectional area

    0 ft. - Water Mark, 35 %of cross sectional area

  • Crack Multiple, from 12 to 02 o'clock, within 8 inches of joint: YES

    13.7 ft. - Crack Multiple, from 12 to 02 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 11 to 05 o'clock, within 8 inches of joint: YES, Start

    26.8 ft. - Crack Multiple, from 11 to 05 o'clock, within 8 inches of joint: YES, Start

  • Roots Fine Joint, from 09 to 11 o'clock, within 8 inches of joint: YES

    37.8 ft. - Roots Fine Joint, from 09 to 11 o'clock, within 8 inches of joint: YES

  • Crack Circumferential, from 07 to 05 o'clock, within 8 inches of joint: YES

    43.7 ft. - Crack Circumferential, from 07 to 05 o'clock, within 8 inches of joint: YES

  • Roots Fine Joint, from 03 to 04 o'clock, within 8 inches of joint: YES

    48.5 ft. - Roots Fine Joint, from 03 to 04 o'clock, within 8 inches of joint: YES

  • Roots Fine Joint, from 03 to 05 o'clock, within 8 inches of joint: YES, Start

    58.8 ft. - Roots Fine Joint, from 03 to 05 o'clock, within 8 inches of joint: YES, Start

  • Crack Multiple, from 12 to 02 o'clock, within 8 inches of joint: YES

    184.6 ft. - Crack Multiple, from 12 to 02 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Start

    199.5 ft. - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Start

All inspections of P15331Work order 557968

Observations (19)

DistanceCodeObservation
0MWM—
48.5RFJ—
2.3DAGS—
327DAGS—
245.1RFJ—
58.8RFJ—
37.8RFJ—
0MWL—
199.5CM—
33.1CM—
0AMH19 0141
13.7CM—
184.6CM—
72.1RFJ—
330.5AMH19 0140
330.5MGOLATERAL AT MH 9 OCLOCK CAPPED
26.8CM—
296.9CM—
43.7CC—

Properties (6)

additional_info
SC305313
custom_field_two
3
customer
LACSD
datetime
2016-03-14T02:09:00-07:00
documentation
PRO-PIPE
is_lateral_inspection
false
