Wastewater/Activity/PacpInspection/1.0Jun 27, 2018, 11:26 AM
02 1544A_02 1544_27062018_043517.mp4
- Date
- 06/27/2018
- W/O
- 712111
- Weather
- Dry
- Operator/Surveyor
- J. BUENROSTRO
- Sewer ID
- Z00230
- PipeID
- P03973
- Time
- 4:26 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K5204
- Sewer Name
- 02 ARIZONA AVENUE TRUNK, SECTION 1
- City
- EAST LOS ANGELES
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 12
- Purpose
- Routine Assessment
- Project
- WO_712111_TV02006_JUL2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 02 1544A
- Downstream MH
- 02 1544
- Dir. of Survey
- Downstream
- Length Surveyed
- 172.6 ft.
- Total Length
- 172.6 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 2
Observation photos (1)
3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 170.4 | DAGS | — |
| 172.6 | AMH | 02 1544 |
| 0 | MWL | — |
| 0 | AMH | 02 1544A |
| 89.6 | TBA | — |
| 0 | MGO | SERVICE CONNECTION AT 9 O'CLOCK AT MH |
| 129.1 | TF | — |
| 3.1 | MGO | LINER |
| 3 | DAGS | — |
| 0 | MWM | — |
| 77 | TF | — |
Properties (5)
- additional_info
- SC359529
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-06-27T04:26:06-07:00
- lining
- CIPP
