Wastewater/Activity/PacpInspection/1.0Nov 15, 2018, 09:48 AM
16 0186_16 0280_11152018_023819.mp4
- Date
- 11/15/2018
- W/O
- 0739072
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00654
- PipeID
- P13329
- Time
- 1:48 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1052R
- Sewer Name
- 16 CHAPEL AVENUE TRUNK, SECTION 3
- City
- PASADENA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 17
- Purpose
- Maintenance Related
- Project
- 20181115MDM_CHAPEL_AVENUE_TRUNK_SECTION_3
- Material
- NRCP
- Shape
- Circular
- Height
- 15 in.
- Upstream MH
- 16 0186
- Downstream MH
- 16 0280
- Dir. of Survey
- Downstream
- Length Surveyed
- 13.9 ft.
- Total Length
- 13.9 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2200
- O&M Rating
- 4
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 4
Observation photos (4)
9.5 ft. - Roots Fine Barrell, from 09 to 01 o'clock, within 8 inches of joint: YES - 2%
10.3 ft. - General Observation - LINK PIPE START- BENT TABS
11.3 ft. - Roots Fine Barrell, from 09 to 03 o'clock, within 8 inches of joint: YES - 3%
13.2 ft. - General Observation - LINK PIPE END-TABS IN PLACE
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWM | — |
| 0 | AMH | 2:30AM |
| 0 | MWL | — |
| 10.3 | MGO | LINK PIPE START- BENT TABS |
| 13.9 | MSA | 2:45AM |
| 13.2 | MGO | LINK PIPE END-TABS IN PLACE |
| 0.1 | MGO | 15" NRCP |
| 11.3 | RFB | 3% |
| 9.5 | RFB | 2% |
Properties (5)
- additional_info
- POST ROOT CCTV
- customer
- LACSD
- datetime
- 2018-11-15T01:48:42-08:00
- documentation
- MARTIN,REVELES,OLIVER 111,BRAR
- is_lateral_inspection
- false
