Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 3, 2018, 04:01 AM

  • _29 0461 _02102018_210851.mp4

Date
10/02/2018
W/O
729479
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00989
PipeID
P24505
Time
9:01 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6122
Sewer Name
29 LEWIS AVENUE SEWER
City
SIGNAL HILL
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
01
Purpose
Routine Assessment
Project
RFIR_WO_729479_TV29059_OCT2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Width
8 in.
Upstream MH
29 0461
Dir. of Survey
Upstream
Length Surveyed
359.7 ft.
Total Length
359.7 ft.
Structural Index
3
Structural Quick
3I00
Structural Rating
150
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
150
Pipe schematic from manhole 29 0461 to unknown
MH: 29 0461MH: —upstream0 ft. AEP - End of Pipe - 00.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"53 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"55.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"58.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"100.5 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish105 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"107.4 ft. RPP - Repair Patch, from 12 to 12 o'clock, within 8 inches of joint: NO151.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"154.6 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"205.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"207.8 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"251.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"254.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"331.8 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"334.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"334.4 ft. RPP - Repair Patch, from 12 to 12 o'clock, within 8 inches of joint: YES344.9 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start350.8 ft. CM - Crack Multiple, from 11 to 01 o'clock, within 8 inches of joint: YES359.7 ft. MWM - Water Mark, 5 %of cross sectional area359.7 ft. AMH - Downstream Manhole, Survey Begins - 29 0461359.7 ft. MWL - Water Level, 5 %of cross sectional area

Observation photos (4)

  • Crack Multiple, from 11 to 01 o'clock, within 8 inches of joint: YES

    8.9 ft. - Crack Multiple, from 11 to 01 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    14.8 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Repair Patch, from 12 to 12 o'clock, within 8 inches of joint: YES

    25.3 ft. - Repair Patch, from 12 to 12 o'clock, within 8 inches of joint: YES

  • Repair Patch, from 12 to 12 o'clock, within 8 inches of joint: NO

    252.3 ft. - Repair Patch, from 12 to 12 o'clock, within 8 inches of joint: NO

All inspections of P24505Work order 729479

Observations (23)

DistanceCodeObservation
0MWM—
25.3TF—
252.3RPP—
359.5TFC—
304.1TF—
25.3RPP—
27.9TF—
205.1TF—
154.5TF—
14.8CM—
151.9TF—
0AMH29 0461
301.4TF—
359.7AEP0
105.3TFC—
356.7TFC—
108.1TF—
0MWL—
306.7TFC—
259.2CM—
254.7TFC—
8.9CM—
207.9TFC—

Properties (4)

additional_info
SC364842
custom_field_two
3
customer
LACSD
datetime
2018-10-02T21:01:59-07:00
