Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 10, 2018, 09:57 AM

  • 16 0040_16 0039 _10102018_025815.mp4

Date
10/10/2018
W/O
729442
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00640
PipeID
P13130
Time
2:57 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6162
Sewer Name
16 ALLEN AVENUE TRUNK, SECTION 3
City
SAN MARINO
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
18
Purpose
Routine Assessment
Project
RFIR_WO_729442_TV16112_OCT2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
16 0039
Downstream MH
16 0040
Dir. of Survey
Upstream
Length Surveyed
7.4 ft.
Total Length
7.4 ft.
Structural Index
3
Structural Quick
3200
Structural Rating
6
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
6
Pipe schematic from manhole 16 0039 to 16 0040
MH: 16 0039MH: 16 0040upstream0 ft. MGO - General Observation - COCKROACHES IN MANHOLE0 ft. AMH - Upstream Manhole, Survey Ends - 16 00400 ft. SAP - Surface Aggregate Projecting, from 12 to 12 o'clock, within 8 inches of joint: YES, Finish5.4 ft. SAP - Surface Aggregate Projecting, from 12 to 12 o'clock, within 8 inches of joint: YES, Start7.4 ft. MWL - Water Level, 5 %of cross sectional area7.4 ft. AMH - Downstream Manhole, Survey Begins - 16 00397.4 ft. MWM - Water Mark, 5 %of cross sectional area7.4 ft. MGO - General Observation - COCKROACHES IN MANHOLE7.4 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 1 O'CLOCK

Observation photos (3)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Surface Aggregate Projecting, from 12 to 12 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Aggregate Projecting, from 12 to 12 o'clock, within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    7.4 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P13130Work order 729442

Observations (9)

DistanceCodeObservation
0MWL—
7.4MGOCOCKROACHES IN MANHOLE
7.4AMH16 0040
0AMH16 0039
7.4SAP—
2SAP—
0MWM—
0MGOCOCKROACHES IN MANHOLE
0MGOACTIVE CONNECTION AT MH 1 O'CLOCK

Properties (4)

additional_info
SC365130
custom_field_two
2
customer
LACSD
datetime
2018-10-10T02:57:59-07:00
