Wastewater/Activity/PacpInspection/1.0Oct 12, 2018, 09:03 AM
02 0005_02 0132_12102018_020317.mp4
- Date
- 10/12/2018
- W/O
- 729318
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00234
- PipeID
- P18010
- Time
- 2:03 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K6147
- Sewer Name
- 02 ARTESIA EXTENSION TRUNK
- City
- BELLFLOWER
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 38
- Purpose
- Routine Assessment
- Project
- RFIR_WO_729318_TV02263_OCT2018
- Sewer Type
- Siphon
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 27 in.
- Width
- 27 in.
- Upstream MH
- 02 0005
- Downstream MH
- 02 0132
- Dir. of Survey
- Downstream
- Length Surveyed
- 8.1 ft.
- Total Length
- 8.1 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 4
- O&M Quick
- 4100
- O&M Rating
- 4
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 7
Observation photos (3)
2.1 ft. - Deposits Settled Other, 25 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start - heavy sludge
2.3 ft. - Surface Aggregate Projecting, from 10 to 02 o'clock, within 8 inches of joint: YES, Start
8.1 ft. - Survey Abandoned - DOWN LEG OF THE U/S SIPHON
Observations (8)
| Distance | Code | Observation |
|---|---|---|
| 8.1 | MSA | DOWN LEG OF THE U/S SIPHON |
| 2.3 | SAP | — |
| 0 | AMH | 02 0005 S |
| 8.1 | SAP | — |
| 0 | MWM | — |
| 2.1 | DSZ | heavy sludge |
| 0 | MWL | — |
| 8.1 | DSZ | — |
Properties (4)
- additional_info
- SC365214
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2018-10-12T02:03:05-07:00
