Wastewater/Activity/PacpInspection/1.0Jul 14, 2017, 09:51 AM
18 1112_18 0302 _14072017_025123.mp4
- Date
- 07/14/2017
- W/O
- 640649
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00711
- PipeID
- P14962
- Time
- 2:51 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4650
- Sewer Name
- 18 STAGE ROAD JUNCTION TRUNK
- City
- SANTA FE SPRINGS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 31
- Purpose
- Routine Assessment
- Project
- WO_640649_TV18058_JUN2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 18 1112
- Downstream MH
- 18 0302
- Dir. of Survey
- Downstream
- Length Surveyed
- 39.3 ft.
- Total Length
- 39.3 ft.
- Structural Index
- 3
- Structural Quick
- 3221
- Structural Rating
- 8
- O&M Index
- 2
- O&M Quick
- 2600
- O&M Rating
- 12
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 20
Observation photos (4)
4.1 ft. - Crack Longitudinal, at 10 o'clock, within 8 inches of joint: YES
5.1 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
9.9 ft. - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: YES, Start
32.1 ft. - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 9.9 | DSZ | — |
| 0 | MWL | — |
| 0 | AMH | 18 1112 |
| 5.1 | CM | — |
| 0 | MWM | — |
| 39.3 | AMH | 18 0302 |
| 39.3 | DSZ | — |
| 32.1 | CM | — |
| 39.3 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 4.1 | CL | — |
Properties (4)
- additional_info
- SC345510
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-07-14T02:51:16-07:00
