Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 25, 2016, 11:51 AM

  • 14 0419A_14 0419_25052016_045200.mp4

Date
05/25/2016
W/O
573476
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00578
PipeID
P18503
Time
4:51 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3510
Sewer Name
14 TRUNK "B"
City
LANCASTER
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 14
Page No.
04
Purpose
Routine Assessment
Project
WO_573476_JUNE2016
Sewer Type
GRAVITY
Material
NRCP
Shape
Circular
Height
15 in.
Upstream MH
14 0419
Downstream MH
14 0419A
Dir. of Survey
Upstream
Length Surveyed
330.7 ft.
Total Length
330.7 ft.
Structural Index
3
Structural Quick
3L00
Structural Rating
195
O&M Index
2
O&M Quick
412L
O&M Rating
134
Overall Index
3
Overall Quick
—
Overall Rating
329
Pipe schematic from manhole 14 0419 to 14 0419A
MH: 14 0419MH: 14 0419Aupstream0 ft. AMH - Upstream Manhole, Survey Ends - 14 0419A1.4 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish1.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish20.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"44.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"66.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"94 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"107.2 ft. MGO - General Observation - RUN LIST STATES MH AT 223'.118.1 ft. TFC - Tap Factory Made Capped, at 03 o'clock, -, within 8 inches of joint: NO, 6"146.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"171.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"196.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"220.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"249.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"273.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"298.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"321.3 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"328.7 ft. MGO - General Observation - MAG COATING 80%328.7 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start328.7 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start330.7 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 9 O'CLOCK330.7 ft. MWL - Water Level, 35 %of cross sectional area330.7 ft. AMH - Downstream Manhole, Survey Begins - 14 0419330.7 ft. MWM - Water Mark, 60 %of cross sectional area

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

All inspections of P18503Work order 573476

Observations (24)

DistanceCodeObservation
9.4TFC—
2MGOMAG COATING 80%
263.8TFC—
212.6TFC—
57.2TFC—
32.3TFC—
329.3SAP—
0MGOACTIVE CONNECTION AT MH 9 O'CLOCK
236.7TFC—
330.7AMH14 0419A
0MWL—
81.6TFC—
2DAGS—
0AMH14 0419
223.5MGORUN LIST STATES MH AT 223'.
2SAP—
134.6TFC—
310.6TFC—
159.2TFC—
184.6TFC—
110.2TFC—
285.9TFC—
0MWM—
329.3DAGS—

Properties (4)

additional_info
SC305640
custom_field_two
3
customer
LACSD
datetime
2016-05-25T04:51:36-07:00
