Wastewater/Activity/PacpInspection/1.0Sep 26, 2017, 07:29 AM
08 0322_08 0321A_26092017_003006.mpg
- Date
- 09/26/2017
- W/O
- 657837
- Weather
- Dry
- Operator/Surveyor
- CORTEZ ESTEBAN
- Sewer ID
- Z00013
- PipeID
- P00370
- Time
- 12:29 AM
- Certificate
- U-209-8148
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4940
- Sewer Name
- 08 KEYSTONE TRUNK
- City
- CARSON
- Loc. details
- Main Highway - Suburban/Rural
- Location Code
- B
- Use of Sewer
- Sanitary Sewer
- District
- District 08
- Page No.
- 13
- Purpose
- Routine Assessment
- Project
- WO_630370_TV05315_AUG2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 08 0322
- Downstream MH
- 08 0321A
- Dir. of Survey
- Downstream
- Length Surveyed
- 71.3 ft.
- Total Length
- 71.3 ft.
- Structural Index
- 3
- Structural Quick
- 4122
- Structural Rating
- 8
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (3)
5.2 ft. - Crack Longitudinal Hinge, 2, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
25.5 ft. - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES, Start
25.5 ft. - Crack Longitudinal, at 03 o'clock, within 8 inches of joint: YES, Start
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWM | — |
| 25.5 | CL | — |
| 5.2 | CH2 | — |
| 25.5 | CL | — |
| 0 | MGO | SERVICE CONNECTION AT 9 O'CLOCK AT MH |
| 71.3 | MGO | SERVICE CONNECTION AT 3 O' CLOCK AT MH |
| 66.4 | CL | — |
| 16.9 | CH2 | — |
| 66.4 | CL | — |
| 0 | AMH | 08 0322 |
| 0 | MWL | — |
| 71.3 | AMH | 08 0321A |
| 0 | MGO | SERVICE CONNECTION AT 3 O' CLOCK AT MH |
| 29.1 | TFC | — |
Properties (4)
- additional_info
- SC345849
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-09-26T00:29:52-07:00
