Wastewater/Activity/PacpInspection/1.0Sep 20, 2017, 05:42 AM
05 0760_05 0759 _09192017_224259.mp4
- Date
- 09/19/2017
- W/O
- 630370
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00484
- PipeID
- P05987
- Time
- 10:42 PM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4979
- Sewer Name
- 05 MANCHESTER-VERMONT RELIEF TRUNK
- City
- LOS ANGELES
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 09
- Purpose
- Routine Assessment
- Project
- WO_630370_TV05315_AUG2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 05 0760
- Downstream MH
- 05 0759
- Dir. of Survey
- Downstream
- Length Surveyed
- 419.2 ft.
- Total Length
- 419.2 ft.
- Structural Index
- 4
- Structural Quick
- 4200
- Structural Rating
- 8
- O&M Index
- 2
- O&M Quick
- 2a00
- O&M Rating
- 336
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 344
Observation photos (3)
3 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Start
3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
3 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 412 | DSC | — |
| 0 | MWL | — |
| 418 | MGO | SPALLING THROUGHOUT THE REACH |
| 3 | DAE | — |
| 3 | DAGS | — |
| 0 | AMH | 05 0760 |
| 0 | MWM | — |
| 419.2 | FM | — |
| 3 | FM | — |
| 297.5 | DSC | — |
| 419.2 | DAE | — |
| 419.2 | DAGS | — |
| 419.2 | AMH | 05 0759 |
Properties (4)
- additional_info
- SC345971
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-09-19T22:42:22-07:00
