Wastewater/Activity/PacpInspection/1.0Oct 18, 2018, 10:38 AM
02 1055_02 1054_10182018_034810.mp4
- Date
- 10/18/2018
- W/O
- #
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00310
- PipeID
- P03626
- Time
- 3:38 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1018
- Sewer Name
- 02 UNION STREET TRUNK
- City
- MONTEBELLO
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 21
- Purpose
- Routine Assessment
- Project
- 20181018MDM_UNION_STREET_TRUNK
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Upstream MH
- 02 1055
- Downstream MH
- 02 1054
- Dir. of Survey
- Downstream
- Length Surveyed
- 12.6 ft.
- Total Length
- 12.6 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 5
- O&M Quick
- 5100
- O&M Rating
- 5
- Overall Index
- 5
- Overall Quick
- —
- Overall Rating
- 5
Observation photos (4)
2 ft. - General Observation - 8" VCP
2 ft. - General Observation - 1
12 ft. - General Observation - ZOOM 12'
12.6 ft. - Downstream Manhole, Survey Ends - 3:55AM STOPLOG IN PLACE
Observations (8)
| Distance | Code | Observation |
|---|---|---|
| 2 | MGO | 8" VCP |
| 0 | MWL | NO FLOW |
| 2 | MGO | 1 |
| 12.6 | AMH | 3:55AM STOPLOG IN PLACE |
| 12 | MGO | ZOOM 12' |
| 0 | AMH | 3:45AM |
| 2 | DSZ | SOIL IN MH & PIPE |
| 0 | MWM | — |
Properties (3)
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2018-10-18T03:38:36-07:00
