Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 5, 2018, 07:16 AM

  • 21 1300_21 1299_1052018_002020.mp4

Date
10/05/2018
W/O
0731552
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00763
PipeID
P25691
Time
12:16 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0996
Sewer Name
21 DISTRICT #21 OUTFALL TRUNK
City
INDUSTRY
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 21
Page No.
28
Purpose
Maintenance Related
Project
20181005MDM_DISTRICT_21_OUTFALL_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
27 in.
Upstream MH
21 1300
Downstream MH
21 1299
Dir. of Survey
Downstream
Length Surveyed
101.4 ft.
Total Length
101.4 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 21 1300 to 21 1299
MH: 21 1300MH: 21 1299downstream0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 12:15AM2 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active2 ft. MGO - General Observation - WHITE COATING 8: TO 4:0013.8 ft. MGP - General Photograph - WHITE COATING15.3 ft. MGO - General Observation - WHITE COATING20.2 ft. MGO - General Observation - PEELING WHITE COATING30.4 ft. MGO - General Observation - WHITE COATIING36.5 ft. MGO - General Observation - WHITE COATING48.1 ft. MGP - General Photograph - NO WHITE COATING ON PIPE63.4 ft. MGP - General Photograph - WHITE COATING90.6 ft. MGO - General Observation - WHITE COATING101.4 ft. MSA - Survey Abandoned - 12:40AM

Observation photos (10)

  • General Observation - WHITE COATING 8: TO 4:00

    2 ft. - General Observation - WHITE COATING 8: TO 4:00

  • General Photograph - WHITE COATING

    13.8 ft. - General Photograph - WHITE COATING

  • General Observation - WHITE COATING

    15.3 ft. - General Observation - WHITE COATING

  • General Observation - PEELING WHITE COATING

    20.2 ft. - General Observation - PEELING WHITE COATING

  • General Observation - WHITE COATIING

    30.4 ft. - General Observation - WHITE COATIING

  • General Observation - WHITE COATING

    36.5 ft. - General Observation - WHITE COATING

  • General Photograph - NO WHITE COATING ON PIPE

    48.1 ft. - General Photograph - NO WHITE COATING ON PIPE

  • General Photograph - WHITE COATING

    63.4 ft. - General Photograph - WHITE COATING

  • General Observation - WHITE COATING

    90.6 ft. - General Observation - WHITE COATING

  • Survey Abandoned - 12:40AM

    101.4 ft. - Survey Abandoned - 12:40AM

All inspections of P25691Work order 0731552

Observations (14)

DistanceCodeObservation
0MWM—
63.4MGPWHITE COATING
2MGOConn. @ Mh, 3 O' Clock. Active
2MGOWHITE COATING 8: TO 4:00
101.4MSA12:40AM
90.6MGOWHITE COATING
0MWL—
30.4MGOWHITE COATIING
13.8MGPWHITE COATING
20.2MGOPEELING WHITE COATING
0AMH12:15AM
36.5MGOWHITE COATING
15.3MGOWHITE COATING
48.1MGPNO WHITE COATING ON PIPE

Properties (4)

additional_info
PRE CLEANING
customer
LACSD
datetime
2018-10-05T00:16:29-07:00
year_laid
20060402
