Wastewater/Activity/PacpInspection/1.0Oct 2, 2018, 08:11 PM
02 2195_02 2194_1022018_131920.mp4
- Date
- 10/02/2018
- W/O
- 0731794
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00253
- PipeID
- P04468
- Time
- 1:11 PM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7823
- Sewer Name
- 02 DOWNEY-BELLFLOWER DIVERSION RELIEF TRUNK
- City
- DOWNEY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 29A
- Purpose
- Routine Assessment
- Project
- 20181002DF_DOWNEY_BELLFLOWER_DIV_REL_TR
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 21 in.
- Upstream MH
- 02 2195
- Downstream MH
- 02 2194
- Dir. of Survey
- Downstream
- Length Surveyed
- 464.3 ft.
- Total Length
- 464.3 ft.
- Structural Index
- 2
- Structural Quick
- 2100
- Structural Rating
- 2
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 2
Observation photos (5)
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
127.8 ft. - General Photograph
127.9 ft. - General Photograph
254.2 ft. - General Photograph
464.2 ft. - General Photograph - LOCAL LINE @ MH
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 461.4 | MGO | GREASE THROUGHOUT THE REACH (5%) |
| 0 | MGO | ROACHES @ MH |
| 464.2 | MGP | LOCAL LINE @ MH |
| 461.2 | SSS | — |
| 127.8 | MGP | — |
| 2 | SSS | — |
| 0 | MWL | — |
| 0 | MWM | — |
| 254.2 | MGP | — |
| 464.3 | AMH | 1:38 PM |
| 0 | AMH | 1:13 PM |
| 127.9 | MGP | — |
Properties (3)
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-10-02T13:11:27-07:00
