Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 25, 2018, 10:54 AM

  • 16 0339_16 0338_9252018_040757.mp4

Date
09/25/2018
W/O
0729304
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00665
PipeID
P13390
Time
3:54 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0983
Sewer Name
16 SAN MARINO OUTFALL TRUNK
City
SAN MARINO
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 14
Page No.
17
Purpose
Capital Improvement Program Assesment
Project
20180921MDM_SAN_MARINO_OUTFALL_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
16 in.
Upstream MH
16 0339
Downstream MH
16 0338
Dir. of Survey
Downstream
Length Surveyed
300.9 ft.
Total Length
300.9 ft.
Structural Index
3
Structural Quick
5232
Structural Rating
38
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
38
Pipe schematic from manhole 16 0339 to 16 0338
MH: 16 0339MH: 16 0338downstream0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 4:05AM3.2 ft. B - Broken, from 08 to 04 o'clock, within 8 inches of joint: YES - MULTIPUL SLIGHT FRACTURES OFFSET3.2 ft. B - Broken, from 02 to 04 o'clock, within 8 inches of joint: YES - CIRCUM SLIGHT5.8 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SLIGHT8 ft. MGO - General Observation - 16" VCP11 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - SL14.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped18.9 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - SL21.6 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL21.6 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL24.2 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL24.2 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - H26.7 ft. FC - Fracture Circumferential, from 11 to 04 o'clock, within 8 inches of joint: YES - SL28.9 ft. FC - Fracture Circumferential, from 08 to 01 o'clock, within 8 inches of joint: YES - SL30 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SLIGHT AT JOINTS30 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - HAIRLINE AT JOINTS30 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES, Start - SLIGHT AT JOINTS30 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES, Start - HAIRLINE AT JOINTS84.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped137.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Active153.7 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Active156.5 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped229.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped271.6 ft. TB - Tap Break-In, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Open294.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped300.6 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - 40% SLIGHT AT JOINTS300.6 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES, Finish - 15% SLIGHT AT JOINTS300.6 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active300.6 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES, Finish - 15% HAIRLINE AT JOINTS300.6 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - 50% HAIRLINE AT JOINTS300.9 ft. AMH - Downstream Manhole, Survey Ends - 4:45AM

Observation photos (2)

  • Broken, from 08 to 04 o'clock, within 8 inches of joint: YES - MULTIPUL SLIGHT FRACTURES OFFSET

    3.2 ft. - Broken, from 08 to 04 o'clock, within 8 inches of joint: YES - MULTIPUL SLIGHT FRACTURES OFFSET

  • Broken, from 02 to 04 o'clock, within 8 inches of joint: YES - CIRCUM SLIGHT

    3.2 ft. - Broken, from 02 to 04 o'clock, within 8 inches of joint: YES - CIRCUM SLIGHT

All inspections of P13390Work order 0729304

Observations (33)

DistanceCodeObservation
300.6FC40% SLIGHT AT JOINTS
229.3TFCCapped
26.7FCSL
30FCSLIGHT AT JOINTS
24.2FCSL
8MGO16" VCP
300.6FL15% SLIGHT AT JOINTS
294.1TFCCapped
300.6MGOConn. @ Mh, 9 O' Clock. Active
0MWM—
21.6FCSL
11FCSL
300.6FL15% HAIRLINE AT JOINTS
271.6TBOpen
300.6FC50% HAIRLINE AT JOINTS
24.2FCH
84.4TFCCapped
28.9FCSL
3.2BMULTIPUL SLIGHT FRACTURES OFFSET
30FCHAIRLINE AT JOINTS
0MWL—
300.9AMH4:45AM
153.7TFActive
0AMH4:05AM
30FLSLIGHT AT JOINTS
18.9FCSL
156.5TFCCapped
21.6FCSL
3.2BCIRCUM SLIGHT
14.9TFCCapped
137.1TFActive
5.8FCSLIGHT
30FLHAIRLINE AT JOINTS

Properties (4)

custom_field_three
BROKEN PIPE -SLIGHT FRACTURES
custom_field_two
2
customer
LACSD
datetime
2018-09-25T03:54:58-07:00
