Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 7, 2017, 09:52 AM

  • Section#6_H 0330_H 0329__872017__G6795.mp4

Date
08/07/2017
W/O
0646404
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00175
PipeID
P10780
Time
2:52 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G6795
Sewer Name
H JOINT OUTFALL H - UNIT 4
City
PICO RIVERA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
19A
Purpose
Capital Improvement Program Assesment
Project
20170807MDM_JOINT_OUTFALL_H_UNIT_4
Material
Reinforced Concrete Pipe
Shape
Circular
Height
57 in.
Upstream MH
H 0330
Downstream MH
H 0329
Dir. of Survey
Downstream
Length Surveyed
582.7 ft.
Total Length
582.7 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
4
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole H 0330 to H 0329
MH: H 0330MH: H 0329downstream0 ft. AMH - Upstream Manhole, Survey Begins - 5:10AM0 ft. MWL - Water Level, 30 %of cross sectional area0 ft. MWM - Water Mark, 50 %of cross sectional area2 ft. MGO - General Observation - MAG COAT 100% START 9:00 TO 3:008 ft. MGP - General Photograph - MAG COAT391.5 ft. MGP - General Photograph528.8 ft. MGP - General Photograph - MAG COAT 100%582.4 ft. MGO - General Observation - MAG COAT 100% FINISH582.7 ft. AMH - Downstream Manhole, Survey Ends - 5:50AM

Observation photos (4)

  • General Observation - MAG COAT 100% START 9:00 TO 3:00

    2 ft. - General Observation - MAG COAT 100% START 9:00 TO 3:00

  • General Photograph - MAG COAT

    8 ft. - General Photograph - MAG COAT

  • General Photograph

    391.5 ft. - General Photograph

  • General Photograph - MAG COAT 100%

    528.8 ft. - General Photograph - MAG COAT 100%

All inspections of P10780Work order 0646404

Observations (9)

DistanceCodeObservation
528.8MGPMAG COAT 100%
0AMH5:10AM
391.5MGP—
582.4MGOMAG COAT 100% FINISH
582.7AMH5:50AM
0MWL—
0MWM—
8MGPMAG COAT
2MGOMAG COAT 100% START 9:00 TO 3:00

Properties (4)

custom_field_three
100% MAG COAT
custom_field_two
5
customer
LACSD
datetime
2017-08-07T02:52:30-07:00
