Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 30, 2017, 07:46 AM

  • 02 1760_02 1759A _29112017_234731.mp4

Date
11/29/2017
W/O
674573
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00254
PipeID
P04107
Time
11:46 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5055
Sewer Name
02 DOWNEY-BELLFLOWER EXTENSION TRUNK
City
PICO RIVERA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
15
Purpose
Routine Assessment
Project
WO_674573_TV02052_DEC2017
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
02 1760
Downstream MH
02 1759A
Dir. of Survey
Downstream
Length Surveyed
85.6 ft.
Total Length
85.6 ft.
Structural Index
3
Structural Quick
3B22
Structural Rating
43
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
43
Pipe schematic from manhole 02 1760 to 02 1759A
MH: 02 1760MH: 02 1759Adownstream0 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Begins - 02 17603 ft. CM - Crack Multiple, from 07 to 12 o'clock, within 8 inches of joint: YES6.2 ft. CM - Crack Multiple, from 01 to 04 o'clock, within 8 inches of joint: YES12.2 ft. CL - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES17.9 ft. CL - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES33 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES36.1 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start84.4 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish85.6 ft. AMH - Downstream Manhole, Survey Ends - 02 1759A85.6 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK

Observation photos (6)

  • Crack Multiple, from 07 to 12 o'clock, within 8 inches of joint: YES

    3 ft. - Crack Multiple, from 07 to 12 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 01 to 04 o'clock, within 8 inches of joint: YES

    6.2 ft. - Crack Multiple, from 01 to 04 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

    12.2 ft. - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

    17.9 ft. - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    33 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    36.1 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P04107Work order 674573

Observations (12)

DistanceCodeObservation
0MGOCONNECTION AT MH 3 O'CLOCK
85.6AMH02 1759A
0MGOCONNECTION AT MH 9 O'CLOCK
3CM—
85.6MGOCONNECTION AT MH 3 O'CLOCK
12.2CL—
33CM—
36.1CM—
0AMH02 1760
6.2CM—
84.4CM—
17.9CL—

Properties (4)

additional_info
SC346284
custom_field_two
3
customer
LACSD
datetime
2017-11-29T23:46:24-08:00
