Wastewater/Activity/PacpInspection/1.0Dec 28, 2016, 09:42 AM
03 0389_03 0382 _12282016_015932.mp4
- Date
- 12/28/2016
- W/O
- 613343
- Weather
- Dry
- Operator/Surveyor
- R.VARGAS
- Sewer ID
- Z00371
- PipeID
- P04961
- Time
- 1:42 AM
- Certificate
- U-209-211
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3901
- Sewer Name
- 03 MARINA TRUNK, SECTION 2
- City
- LONG BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 25
- Purpose
- Routine Assessment
- Project
- WO_613343_TV03019_JAN2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 03 0389
- Downstream MH
- 03 0382
- Dir. of Survey
- Downstream
- Length Surveyed
- 490 ft.
- Total Length
- 490.1 ft.
- Structural Index
- 1
- Structural Quick
- 1100
- Structural Rating
- 1
- O&M Index
- 2
- O&M Quick
- 312Z
- O&M Rating
- 269
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 270
Observation photos (2)
2.5 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
7 ft. - Crack Circumferential, from 11 to 01 o'clock, within 8 inches of joint: YES
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 309.2 | OBZ | DEBRIS NOT VISIBLE |
| 488.9 | OBZ | DEBRIS NOT VISIBLE |
| 490.1 | OBZ | DEBRIS NOT VISIBLE |
| 7 | CC | — |
| 0 | MWL | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK CAPPED |
| 2.5 | MGO | MAGNESIUM H.O. START |
| 2.5 | DAGS | — |
| 0 | MGO | CONNECTION AT MH 9 O'CLOCK MADE |
| 490.1 | AMH | 03 0382 |
| 488.9 | MGO | MAGNEZIUM H.O. FINISH |
| 488.9 | DAGS | — |
| 0 | MWM | — |
| 0 | AMH | 03 0389 |
Properties (4)
- additional_info
- SC305242
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-12-28T01:42:40-08:00
