Wastewater/Activity/PacpInspection/1.0Jun 1, 2017, 09:21 AM
B 0408_B 0407 _01062017_032013.mp4
- Date
- 06/01/2017
- W/O
- 641038
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00092
- PipeID
- P08920
- Time
- 2:21 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4542
- Sewer Name
- B JOINT OUTFALL B - UNIT 5B
- City
- ARCADIA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 07
- Purpose
- Routine Assessment
- Project
- WO_641038_TV15053_JUN2017
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 21 in.
- Width
- 21 in.
- Upstream MH
- B 0408
- Downstream MH
- B 0407
- Dir. of Survey
- Downstream
- Length Surveyed
- 241.5 ft.
- Total Length
- 241.5 ft.
- Structural Index
- 3
- Structural Quick
- 3H2H
- Structural Rating
- 235
- O&M Index
- 2
- O&M Quick
- 2H00
- O&M Rating
- 94
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 329
Observation photos (3)
4.7 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
4.7 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
4.7 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (15)
| Distance | Code | Observation |
|---|---|---|
| 4.7 | SSS | — |
| 241.5 | SAV | — |
| 99.2 | TF | — |
| 4.7 | DAGS | — |
| 0 | AMH | B 0408 |
| 4.7 | SAV | — |
| 241.5 | AMH | B 0407 |
| 0 | MWL | — |
| 154.6 | TF | — |
| 89.9 | TF | — |
| 241.5 | MGO | CONNECTION AT 3 OC |
| 0 | MWM | — |
| 241.5 | DAGS | — |
| 241.5 | SSS | — |
| 219.8 | TF | — |
Properties (4)
- additional_info
- SC345357
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-06-01T02:21:30-07:00
