Wastewater/Activity/PacpInspection/1.0Sep 12, 2018, 08:45 AM
02 1833_02 1832_9122018_021512.mp4
- Date
- 09/12/2018
- W/O
- #
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00240
- PipeID
- P04183
- Time
- 1:45 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H0973
- Sewer Name
- 02 CITY TERRACE DIVERSION EXTENSION TRUNK
- City
- LOS ANGLES
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 08
- Purpose
- Capital Improvement Program Assesment
- Project
- 20180912MDM_CITY_TERRACE_DIVERSION_EXTENSION_TRUNK
- Material
- NRCP
- Shape
- Circular
- Height
- 18 in.
- Upstream MH
- 02 1832
- Downstream MH
- 02 1833
- Dir. of Survey
- Upstream
- Length Surveyed
- 200.9 ft.
- Total Length
- 200.9 ft.
- Structural Index
- 2
- Structural Quick
- 2100
- Structural Rating
- 2
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 2
Observation photos (2)
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - FLAKING CONCRETE
2 ft. - General Observation - MAG COAT 100% START
Observations (8)
| Distance | Code | Observation |
|---|---|---|
| 2 | SSS | FLAKING CONCRETE |
| 200.5 | SSS | FLAKING CONCRETE UNDER MAG COAT |
| 0 | AMH | 2:20AM |
| 2 | MGO | MAG COAT 100% START |
| 0 | MWM | — |
| 0 | MWL | — |
| 200.5 | MGO | 100% MAG COAT FINISH |
| 200.9 | AMH | 2:35AM(COMPLETED REVERSE INSPECTION) |
Properties (4)
- custom_field_three
- 100% MAG COAT
- custom_field_two
- 5
- customer
- LACSD
- datetime
- 2018-09-12T01:45:29-07:00
