Wastewater/Activity/PacpInspection/1.0Apr 7, 2017, 10:20 AM
18 0157_18 0156_20170407_034318.mp4
- Date
- 04/07/2017
- W/O
- 624437
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00695
- PipeID
- P13980
- Time
- 3:20 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4344
- Sewer Name
- 18 ORR AND DAY ROAD TRUNK
- City
- NORWALK
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 24
- Purpose
- Routine Assessment
- Project
- WO_624437_TV18043_MAR2017
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 30 in.
- Width
- 30 in.
- Upstream MH
- 18 0156
- Downstream MH
- 18 0157
- Dir. of Survey
- Upstream
- Length Surveyed
- 264 ft.
- Total Length
- 264 ft.
- Structural Index
- 1
- Structural Quick
- 1100
- Structural Rating
- 1
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 3
Observation photos (1)
1.7 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 264 | DAGS | — |
| 0 | AMH | 18 0156 |
| 264 | SRI | — |
| 264 | AMH | 18 0157 |
| 1.7 | DAGS | — |
| 0 | MWL | — |
| 1.7 | SRI | — |
| 0 | MWM | — |
| 264 | MGO | CONNECTION AT 9 OC |
| 264 | MGO | CONNECTION AT 3 OC |
Properties (4)
- additional_info
- SC340708
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-04-07T03:20:38-07:00
