Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 3, 2018, 10:38 AM

  • 01 0262_01 0261_03082018_034951.mp4

Date
08/03/2018
W/O
717715
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00218
PipeID
P01308
Time
3:38 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5965
Sewer Name
01 SOUTH PARK AVENUE TRUNK
City
LOS ANGELES
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
09
Purpose
Routine Assessment
Project
WO_717715_TV01205_AUG2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
01 0262
Downstream MH
01 0261
Dir. of Survey
Downstream
Length Surveyed
334.7 ft.
Total Length
334.7 ft.
Structural Index
4
Structural Quick
4L31
Structural Rating
259
O&M Index
1
O&M Quick
1100
O&M Rating
1
Overall Index
4
Overall Quick
—
Overall Rating
260
Pipe schematic from manhole 01 0262 to 01 0261
MH: 01 0262MH: 01 0261downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01 02620 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK0 ft. MWM - Water Mark, 25 %of cross sectional area5.7 ft. CM - Crack Multiple, from 09 to 04 o'clock, within 8 inches of joint: YES9.3 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start69.5 ft. RFJ - Roots Fine Joint, from 01 to 03 o'clock, within 8 inches of joint: YES92.7 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"122.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"158.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"244.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"274.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"330.3 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish334.7 ft. AMH - Downstream Manhole, Survey Ends - 01 0261334.7 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK334.7 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK

Observation photos (4)

  • Crack Multiple, from 09 to 04 o'clock, within 8 inches of joint: YES

    5.7 ft. - Crack Multiple, from 09 to 04 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    9.3 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Roots Fine Joint, from 01 to 03 o'clock, within 8 inches of joint: YES

    69.5 ft. - Roots Fine Joint, from 01 to 03 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

    330.3 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

All inspections of P01308Work order 717715

Observations (16)

DistanceCodeObservation
69.5RFJ—
92.7TFC—
9.3FM—
244.2TF—
5.7CM—
0MWL—
122.8TF—
0AMH01 0262
334.7AMH01 0261
334.7MGOCONNECTION AT MH 9 O'CLOCK
330.3FM—
158.9TF—
0MGOCONNECTION AT MH 3 O'CLOCK
0MWM—
274.4TFC—
334.7MGOCONNECTION AT MH 3 O'CLOCK

Properties (4)

additional_info
SC364728
custom_field_two
2
customer
LACSD
datetime
2018-08-03T03:38:23-07:00
