Wastewater/Activity/PacpInspection/1.0Jul 26, 2018, 09:29 AM
05 1295_05 1378 _26072018_023421.mp4
- Date
- 07/26/2018
- W/O
- 717157
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00487
- PipeID
- P06598
- Time
- 2:29 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5798
- Sewer Name
- 05 MONETA TRUNK
- City
- GARDENA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 21
- Purpose
- Routine Assessment
- Project
- WO_718157_TV05336_AUG2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 10 in.
- Width
- 10 in.
- Upstream MH
- 05 1295
- Downstream MH
- 05 1378
- Dir. of Survey
- Downstream
- Length Surveyed
- 29.3 ft.
- Total Length
- 29.3 ft.
- Structural Index
- 3
- Structural Quick
- 4233
- Structural Rating
- 17
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 17
Observation photos (2)
4.3 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
18 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 29.3 | AMH | 05 1378 |
| 29.3 | FM | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 18 | FM | — |
| 29.3 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 29.3 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 4.3 | CM | — |
| 0 | AMH | 05 1295 |
| 0 | MWM | — |
| 18 | CM | — |
Properties (4)
- additional_info
- SC364710
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2018-07-26T02:29:18-07:00
