Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 24, 2018, 08:44 AM

  • 08 0369_08 0368 _24072018_015114.mp4

Date
07/24/2018
W/O
717825
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00003
PipeID
P00421
Time
1:44 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5792
Sewer Name
08 DAVIDSON CITY TRUNK, SECTS 1,2,&3
City
CARSON
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 08
Page No.
12
Purpose
Routine Assessment
Project
WO_717825_TV08001_AUG2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
08 0369
Downstream MH
08 0368
Dir. of Survey
Downstream
Length Surveyed
141.4 ft.
Total Length
141.4 ft.
Structural Index
3
Structural Quick
3E00
Structural Rating
84
O&M Index
2
O&M Quick
2B11
O&M Rating
35
Overall Index
3
Overall Quick
—
Overall Rating
119
Pipe schematic from manhole 08 0369 to 08 0368
MH: 08 0369MH: 08 0368downstream0 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 08 03692.3 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start42.8 ft. RFJ - Roots Fine Joint, from 10 to 02 o'clock, within 8 inches of joint: YES42.8 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: NO, 6"55.7 ft. RFB - Roots Fine Barrell, from 09 to 03 o'clock, Start70.7 ft. TFC - Tap Factory Made Capped, at 12 o'clock, -, within 8 inches of joint: NO, 6"101.7 ft. TFC - Tap Factory Made Capped, at 12 o'clock, -, within 8 inches of joint: NO, 6"127.3 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: NO, 6"141.4 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish141.4 ft. RFB - Roots Fine Barrell, from 09 to 03 o'clock, Finish141.4 ft. MGO - General Observation - CAPPED LATERAL 9 O'CLOCK @ MH141.4 ft. AMH - Downstream Manhole, Survey Ends - 08 0368

Observation photos (2)

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2.3 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Roots Fine Barrell, from 09 to 03 o'clock, Start

    55.7 ft. - Roots Fine Barrell, from 09 to 03 o'clock, Start

All inspections of P00421Work order 717825

Observations (14)

DistanceCodeObservation
0MWM—
141.4SAV—
42.8RFJ—
141.4RFB—
2.3SAV—
55.7RFB—
0MWL—
70.7TFC—
101.7TFC—
141.4MGOCAPPED LATERAL 9 O'CLOCK @ MH
0AMH08 0369
127.3TF—
42.8TF—
141.4AMH08 0368

Properties (4)

additional_info
SC364703
custom_field_two
3
customer
LACSD
datetime
2018-07-24T01:44:22-07:00
