Wastewater/Activity/PacpInspection/1.0Jul 23, 2018, 10:44 AM
05 1514_05 1513 _23072018_040318.mp4
- Date
- 07/23/2018
- W/O
- 717761
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00528
- PipeID
- P06736
- Time
- 3:44 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5787
- Sewer Name
- 05 TORRANCE EXTENSION TRUNK
- City
- TORRANCE
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 29
- Purpose
- Routine Assessment
- Project
- WO_717761_TV05210_AUG2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 10 in.
- Width
- 10 in.
- Upstream MH
- 05 1514
- Downstream MH
- 05 1513
- Dir. of Survey
- Downstream
- Length Surveyed
- 360.5 ft.
- Total Length
- 360.5 ft.
- Structural Index
- 3
- Structural Quick
- 413M
- Structural Rating
- 208
- O&M Index
- 1
- O&M Quick
- 1A00
- O&M Rating
- 12
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 220
Observation photos (3)
22.5 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
167.2 ft. - Fracture Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES
209 ft. - Roots Fine Joint, from 07 to 05 o'clock, within 8 inches of joint: YES, Start
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 268 | RFJ | — |
| 265.2 | TF | — |
| 22.5 | CM | — |
| 209 | RFJ | — |
| 167.2 | FM | — |
| 0 | MWL | — |
| 360.5 | CM | — |
| 165.1 | TFC | — |
| 0 | MWM | — |
| 360.5 | AMH | 05 1513 |
| 0 | AMH | 05 1514 |
Properties (4)
- additional_info
- SC359698
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-07-23T03:44:24-07:00
