Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 11, 2018, 05:46 AM

  • B 0728A_B 0728 _10072018_230131.mp4

Date
07/10/2018
W/O
712477
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00111
PipeID
P09193
Time
10:46 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5770
Sewer Name
B JOINT OUTFALL B - UNIT 8H
City
DUARTE
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
02
Purpose
Routine Assessment
Project
WO_712477_TV22165_JUL2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
B 0728A
Downstream MH
B 0728
Dir. of Survey
Downstream
Length Surveyed
338 ft.
Total Length
338 ft.
Structural Index
3
Structural Quick
423L
Structural Rating
207
O&M Index
1
O&M Quick
1100
O&M Rating
1
Overall Index
3
Overall Quick
—
Overall Rating
208
Pipe schematic from manhole B 0728A to B 0728
MH: B 0728AMH: B 0728downstream0 ft. AMH - Upstream Manhole, Survey Begins - B 0728A0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK10.9 ft. CC - Crack Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES12.2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start12.2 ft. RFJ - Roots Fine Joint, from 08 to 04 o'clock, within 8 inches of joint: YES117.1 ft. FM - Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES125 ft. FS - Fracture Spiral, from 07 to 08 o'clock, within 8 inches of joint: YES166.5 ft. FM - Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES338 ft. MGO - General Observation - CAPPED LATERAL 3 O'CLOCK @ MH338 ft. AMH - Downstream Manhole, Survey Ends - B 0728338 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK338 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

Observation photos (6)

  • Crack Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES

    10.9 ft. - Crack Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    12.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Roots Fine Joint, from 08 to 04 o'clock, within 8 inches of joint: YES

    12.2 ft. - Roots Fine Joint, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES

    117.1 ft. - Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES

  • Fracture Spiral, from 07 to 08 o'clock, within 8 inches of joint: YES

    125 ft. - Fracture Spiral, from 07 to 08 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES

    166.5 ft. - Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES

All inspections of P09193Work order 712477

Observations (14)

DistanceCodeObservation
338MGOCAPPED LATERAL 3 O'CLOCK @ MH
166.5FM—
117.1FM—
0AMHB 0728A
338AMHB 0728
0MWL—
12.2CM—
125FS—
10.9CC—
0MWM—
12.2RFJ—
338MGOCONNECTION AT MH 9 O'CLOCK
338CM—
0MGOCONNECTION AT MH 9 O'CLOCK

Properties (4)

additional_info
SC359679
custom_field_two
3
customer
LACSD
datetime
2018-07-10T22:46:39-07:00
