Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 2, 2018, 09:06 PM

  • 29 0094_29 0093_722018_140853.mp4

Date
07/02/2018
W/O
0711161
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00273
PipeID
P23875
Time
2:06 PM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7748
Sewer Name
29 33RD STREET SEWER
City
SIGNAL HILL
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
01
Purpose
Routine Assessment
Project
20180629DF_33RD_STREET_SEWER
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Upstream MH
29 0093
Downstream MH
29 0094
Dir. of Survey
Upstream
Length Surveyed
91.4 ft.
Total Length
91.4 ft.
Structural Index
2
Structural Quick
2100
Structural Rating
2
O&M Index
2
O&M Quick
2100
O&M Rating
2
Overall Index
2
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole 29 0093 to 29 0094
MH: 29 0093MH: 29 0094upstream0 ft. AMH - Upstream Manhole, Survey Ends - 2:16 PM0 ft. MGO - General Observation - GREASE THROUGHOUT THE REACH (5%)1.5 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish26.5 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: YES, 4"46.5 ft. MGP - General Photograph78.1 ft. TFC - Tap Factory Made Capped, at 09 o'clock, -, within 8 inches of joint: YES, 4"86.5 ft. TBC - Tap Break-In Capped, at 03 o'clock, -, within 8 inches of joint: YES, 4"89.4 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start91.4 ft. MWL - Water Level, 10 %of cross sectional area91.4 ft. MWM - Water Mark, 15 %of cross sectional area91.4 ft. AMH - Downstream Manhole, Survey Begins - 2:07 PM91.4 ft. MGO - General Observation - ROACHES @ MH

Observation photos (2)

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • General Photograph

    44.9 ft. - General Photograph

All inspections of P23875Work order 0711161

Observations (12)

DistanceCodeObservation
2SSS—
91.4AMH2:16 PM
13.3TFC—
44.9MGP—
64.9TBA—
89.9SSS—
0MWL—
4.9TBC—
0MWM—
0AMH2:07 PM
91.4MGOGREASE THROUGHOUT THE REACH (5%)
0MGOROACHES @ MH

Properties (3)

custom_field_two
3
customer
LACSD
datetime
2018-07-02T14:06:27-07:00
