Wastewater/Activity/PacpInspection/1.0Jun 14, 2018, 08:25 AM
05 1469_05 1468 _14062018_014441.mp4
- Date
- 06/14/2018
- W/O
- 707009
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00438
- PipeID
- P06691
- Time
- 1:25 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5730
- Sewer Name
- 05 EL NIDO TRUNK
- City
- TORRANCE
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 23
- Purpose
- Routine Assessment
- Project
- WO_707009_TV05300_JUN2018
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 05 1469
- Downstream MH
- 05 1468
- Dir. of Survey
- Downstream
- Length Surveyed
- 326.5 ft.
- Total Length
- 326.5 ft.
- Structural Index
- 3
- Structural Quick
- 3L2L
- Structural Rating
- 320
- O&M Index
- 2
- O&M Quick
- 2L00
- O&M Rating
- 128
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 448
Observation photos (3)
2 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (20)
| Distance | Code | Observation |
|---|---|---|
| 324.4 | SSS | — |
| 326.5 | AMH | 05 1468 |
| 315.6 | TFC | — |
| 215.5 | TFC | — |
| 324.4 | SAP | — |
| 0 | AMH | 05 1469 |
| 264.5 | TFC | — |
| 164.2 | TFC | — |
| 0 | MWL | — |
| 0 | MWM | — |
| 324.4 | DAGS | — |
| 2 | SAP | — |
| 9.6 | TFC | — |
| 63.8 | TFC | — |
| 166.8 | TFC | — |
| 2 | DAGS | — |
| 326.5 | MGO | CAPPED CONNECTION AT MH 3 O'CLOCK |
| 0 | MGO | CAPPED CONNECTION AT MH 3 O'CLOCK |
| 115.4 | TFC | — |
| 2 | SSS | — |
Properties (4)
- additional_info
- SC359396
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2018-06-14T01:25:57-07:00
