Wastewater/Activity/PacpInspection/1.0Jun 5, 2018, 06:33 AM
22 0657_22 0656 _04062018_234940.mp4
- Date
- 06/04/2018
- W/O
- 701523
- Weather
- Dry
- Operator/Surveyor
- K. ADAME
- Sewer ID
- Z00827
- PipeID
- P17005
- Time
- 11:33 PM
- Certificate
- U-0817-07009000
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5635
- Sewer Name
- 22 SUNFLOWER TRUNK
- City
- SAN DIMAS, CA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 22
- Purpose
- Routine Assessment
- Project
- WO_701523_TV22166_MAY2018
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 22 0657
- Downstream MH
- 22 0656
- Dir. of Survey
- Downstream
- Length Surveyed
- 302.9 ft.
- Total Length
- 302.9 ft.
- Structural Index
- 3
- Structural Quick
- 3321
- Structural Rating
- 11
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 11
Observation photos (4)
2.1 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: NO, Start
109.9 ft. - Fracture Longitudinal, at 04 o'clock, within 8 inches of joint: YES
109.9 ft. - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES
182.5 ft. - Surface Spalling, from 10 to 02 o'clock, within 8 inches of joint: NO, Start
Observations (16)
| Distance | Code | Observation |
|---|---|---|
| 302.9 | AMH | 22 0656 |
| 233.3 | TFC | — |
| 62.6 | TFC | — |
| 2.1 | SAV | — |
| 109.9 | FL | — |
| 0 | AMH | 22 0657 |
| 0 | MWM | — |
| 0 | MWL | — |
| 135.5 | TFC | — |
| 259.3 | SSS | — |
| 109.9 | FL | — |
| 182.5 | SSS | — |
| 237.8 | TFC | — |
| 273.1 | TB | — |
| 300.9 | SAV | — |
| 58.1 | TFC | — |
Properties (4)
- additional_info
- SC359190
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-06-04T23:33:11-07:00
