Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 19, 2018, 07:40 AM

  • Section#1_02 0391_02 0390__6192018__I0028R.mp4

Date
06/19/2018
W/O
0712825
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00250
PipeID
P02710
Time
12:40 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
I0028R
Sewer Name
02 DOWNEY AVENUE EXTENSION TRUNK
City
DOWNEY
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
36
Purpose
Maintenance Related
Project
20180619MDM_DOWNEY_AVENUE_EXTENSION_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
02 0391
Downstream MH
02 0390
Dir. of Survey
Downstream
Length Surveyed
8.2 ft.
Total Length
8.2 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
3
O&M Quick
3121
O&M Rating
5
Overall Index
3
Overall Quick
—
Overall Rating
5
Pipe schematic from manhole 02 0391 to 02 0390
MH: 02 0391MH: 02 0390downstream0 ft. AMH - Downstream Manhole, Survey Begins - 12:50AM0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 20 %of cross sectional area3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - STUB8 ft. RML - Roots Medium Lateral, from 02 to 05 o'clock, 15 %, within 8 inches of joint: YES8 ft. TFD - Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - ACTIVE-90% ROOTS8.2 ft. AMH - Upstream Manhole, Survey Ends - 1:00AM

Observation photos (2)

  • Roots Medium Lateral, from 02 to 05 o'clock, 15 %, within 8 inches of joint: YES

    8 ft. - Roots Medium Lateral, from 02 to 05 o'clock, 15 %, within 8 inches of joint: YES

  • Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - ACTIVE-90% ROOTS

    8 ft. - Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - ACTIVE-90% ROOTS

All inspections of P02710Work order 0712825

Observations (7)

DistanceCodeObservation
8RML—
0AMH12:50AM
3TFCSTUB
0MWL—
8TFDACTIVE-90% ROOTS
8.2AMH1:00AM
0MWM—

Properties (3)

additional_info
REVERSE INSPECTION-ROOT EVALUATION ONLY
customer
LACSD
datetime
2018-06-19T00:40:19-07:00
