Wastewater/Activity/PacpInspection/1.0May 31, 2018, 08:49 AM
01 0233A_01 0233_31052018_020112.mp4
- Date
- 05/31/2018
- W/O
- 707007
- Weather
- Dry
- Operator/Surveyor
- J. BUENROSTRO
- Sewer ID
- Z00218
- PipeID
- P01277
- Time
- 1:49 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K5179
- Sewer Name
- 01 SOUTH PARK AVENUE TRUNK
- City
- LOS ANGELES
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 12
- Purpose
- Routine Assessment
- Project
- WO_707007_TV01204_JUN2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 27 in.
- Width
- 27 in.
- Upstream MH
- 01 0233A
- Downstream MH
- 01 0233
- Dir. of Survey
- Downstream
- Length Surveyed
- 307 ft.
- Total Length
- 307 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 3
- O&M Quick
- 4121
- O&M Rating
- 6
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 6
Observation photos (1)
2.5 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 305.1 | DAGS | — |
| 2.5 | MGO | LINER |
| 0 | AMH | 01 0233A |
| 210.3 | TB | — |
| 307 | AMH | 01 0233 |
| 0.1 | MGO | SERVICE CONNECTION AT 9 O'CLOCK AT MH |
| 2.5 | DAGS | — |
| 0 | MWL | — |
| 0 | MWM | — |
Properties (5)
- additional_info
- SC355100
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2018-05-31T01:49:34-07:00
- lining
- CIPP
