Wastewater/Activity/PacpInspection/1.0May 29, 2018, 09:53 AM
01 0265_01 0264_29052018_030804.mp4
- Date
- 05/29/2018
- W/O
- 707007
- Weather
- Dry
- Operator/Surveyor
- J. BUENROSTRO
- Sewer ID
- Z00218
- PipeID
- P01311
- Time
- 2:53 AM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K5176
- Sewer Name
- 01 SOUTH PARK AVENUE TRUNK
- City
- LOS ANGELES
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 09
- Purpose
- Routine Assessment
- Project
- WO_707007_TV01204_JUN2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 01 0265
- Downstream MH
- 01 0264
- Dir. of Survey
- Downstream
- Length Surveyed
- 335.3 ft.
- Total Length
- 335.3 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 2
Observation photos (1)
4.3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 0 | AMH | 01 0265 |
| 0 | MWL | — |
| 175.8 | TF | — |
| 335.3 | MGO | SERVICE CONNECTION AT 3 O' CLOCK AT MH |
| 148.3 | TFA | POSSIBLE DAMAGED CONNECTION |
| 239.9 | TF | POSSIBLE LARGE GAP AT THE BOTTOM OF THE CONN. |
| 0 | MWM | — |
| 332.7 | DAGS | — |
| 4.3 | DAGS | — |
| 0 | MGO | SERVICE CONNECTION AT 3 O' CLOCK AT MH |
| 335.3 | AMH | 01 0264 |
| 0 | MGO | SERVICE CONNECTION AT 9 O'CLOCK AT MH |
| 0 | MGO | LINER |
Properties (5)
- additional_info
- SC355097
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2018-05-29T02:53:13-07:00
- lining
- CIPP
