Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 10, 2018, 07:37 AM

  • 18 0740_18 0739 _10052018_005203.mp4

Date
05/10/2018
W/O
701125
Weather
Dry
Operator/Surveyor
E.RUIZ
Sewer ID
Z00706
PipeID
P14593
Time
12:37 AM
Certificate
U-715-07000753
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K5317
Sewer Name
18 SO WHITTIER OUTFALL TR, SECTS 1,2,3,&4
City
WHITTIER
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
26
Purpose
Routine Assessment
Project
WO_701125_TV18104_MAY2018
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
33 in.
Width
33 in.
Upstream MH
18 0740
Downstream MH
18 0739
Dir. of Survey
Downstream
Length Surveyed
426 ft.
Total Length
426 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
4
Overall Quick
—
Overall Rating
7
Pipe schematic from manhole 18 0740 to 18 0739
MH: 18 0740MH: 18 0739downstream0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. MWL - Water Level, 35 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 18 07409.9 ft. MGO - General Observation - MAGNEZIUM H.O COATING start19.2 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start220.1 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 8"425 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish425.1 ft. MGO - General Observation - MAGNEZIUM H.O COATING finish426 ft. AMH - Downstream Manhole, Survey Ends - 180739

Observation photos (1)

  • Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    19.2 ft. - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

All inspections of P14593Work order 701125

Observations (9)

DistanceCodeObservation
19.2SAP—
220.1TFA—
425.1MGOMAGNEZIUM H.O COATING finish
426AMH180739
0MWM—
9.9MGOMAGNEZIUM H.O COATING start
0MWL—
0AMH18 0740
425SAP—

Properties (3)

custom_field_two
3
customer
LACSD
datetime
2018-05-10T00:37:56-07:00
