Wastewater/Activity/PacpInspection/1.0Jul 21, 2017, 05:54 AM
02 1254_02 1253 _20072017_225443.mp4
- Date
- 07/20/2017
- W/O
- 646745
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00303
- PipeID
- P03758
- Time
- 10:54 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4756
- Sewer Name
- 02 SANTA ANITA OUTFALL TRUNK
- City
- MONTEBELLO
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 15
- Purpose
- Routine Assessment
- Project
- WO_646745_TV02120_JUL2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 02 1253
- Downstream MH
- 02 1254
- Dir. of Survey
- Upstream
- Length Surveyed
- 292.4 ft.
- Total Length
- 292.4 ft.
- Structural Index
- 2
- Structural Quick
- 3125
- Structural Rating
- 13
- O&M Index
- 3
- O&M Quick
- 3100
- O&M Rating
- 3
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 16
Observation photos (4)
253.2 ft. - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES, Start
257.6 ft. - Crack Multiple, from 03 to 06 o'clock, within 8 inches of joint: YES
267 ft. - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES, Start
284.9 ft. - Deposits Settled Other, 15 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO - SLUDGE
Observations (16)
| Distance | Code | Observation |
|---|---|---|
| 292.4 | MGO | CONNECTION AT MH 12 O'CLOCK |
| 257.6 | CM | — |
| 31.1 | TF | — |
| 206 | TF | — |
| 284.9 | DSZ | SLUDGE |
| 154.6 | TF | — |
| 292.4 | AMH | 02 1254 |
| 257.6 | CL | — |
| 272.3 | TF | — |
| 0 | MWL | — |
| 78.3 | TFA | — |
| 267 | CL | — |
| 0 | AMH | 02 1253 |
| 0 | MWM | — |
| 253.2 | CL | — |
| 289.4 | CL | — |
Properties (4)
- additional_info
- SC345516
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-07-20T22:54:37-07:00
