Wastewater/Activity/PacpInspection/1.0May 21, 2018, 05:22 PM
19 0109_WILDER A_5212018_104446.mp4
- Date
- 05/21/2018
- W/O
- 0700687
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00722
- PipeID
- P21162
- Time
- 10:22 AM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7716
- Sewer Name
- 19 EAST ARTESIA TRUNK, SECTS 1,2,3,&5
- City
- CERRITOS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 19
- Page No.
- 07
- Purpose
- Routine Assessment
- Project
- 20180517DF_EAST_ARTESIA_TRUNK_SECTS_1_2_3_5_
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 21 in.
- Upstream MH
- 19 0109
- Downstream MH
- WILDER A
- Dir. of Survey
- Downstream
- Length Surveyed
- 95.6 ft.
- Total Length
- 95.6 ft.
- Structural Index
- 2
- Structural Quick
- 2100
- Structural Rating
- 2
- O&M Index
- 3
- O&M Quick
- 4121
- O&M Rating
- 6
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (3)
0 ft. - Upstream Manhole, Survey Begins - 10: 40 AM
2 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 10 to 02 o'clock, , within 8 inches of joint: YES, Start
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWM | — |
| 94.6 | SSS | — |
| 0 | MGO | ROACHES @ MH |
| 0 | AMH | 10: 40 AM |
| 95.6 | AMH | 11:19 AM |
| 2 | DAGS | — |
| 94.6 | DAGS | — |
| 95.6 | MGO | GREASE THROUGHOUT THE REACH (5%) |
| 0 | MWL | — |
| 2 | SSS | — |
Properties (3)
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-05-21T10:22:43-07:00
